SKU: 210000128895

2022 Orbea Occam M-LTD

SKU: 210000128895

2022 Orbea Occam M-LTD

$8,699.00
Brand: Orbea
Categories:
More Information
call to customize

Product Description

Stand out from the flock in form and in function. The 2022 Orbea Occam M-LTD is perfectly conceptualized and constructed to implement authoritative performance in every situation. Confidently breeze your way through whatever the trail has in store.

The Orbea Occam perfectly encapsulates the essence of trail mountain biking. Rocking 140mm Fox Float front and rear suspension with three different suspension settings at the tap of a remote, you can truly customize your suspension performance to provide optimized feedback for every scenario. This feature allows you to fly up climbs, punch through undulating cross country terrain, and demonically tear down the mountain. The suspension in the Orbea Occam M-LTD is progressive. This means that bigger hits won’t bottom out your suspension; more resistance is offered the deeper you push into the Occam M-LTD’s shocks. Furthermore, the Occam M-LTD comes with a Fox Transfer Factory dropper post to ensure that you have optimal control over the bike when descending and jumping.

The Orbea Occam M-LTD is flat out flattering. The asymmetrical brace between the seat tube and the downtube catches the eye, has a proprietary built-in multi-tool, and offers enough room to comfortably fit a water bottle. The handy 4 key multi-tool is tightly held in place by powerful magnets; this thoughtful touch allows you to save jersey and saddle-bag room. The offset shock isn’t just a stylistic element. Placing the shock on the left side of the frame allows for the right-side support to become centralized. This efficiently redirects forces acting on the front triangle and enables higher stiffness in stressed areas without adding weight.

In order to further increase weight savings, Orbea blends high modulus and high strength carbon fibers in a standard layup to improve the stiffness-to-weight ratios of critical frame areas. Orbea’s Monocoque Race carbon frames assure uniformness in the frame, especially in key areas, such as the bottom bracket, where unconformities tend to occur.

The Occam M-LTD comes with fully internal cable routing and Orbea uses silicon plugs at the frame entry and exit positions alongside clever conduits that link the front and rear triangle so your cables are fully protected. Internally routed cables are easy on the eye as well, they allow the frame to become the focal point of Orbea’s artfully designed masterpiece.

Come into Contender Bicycles today to get your hands on this highly anticipated trail mountain bike.

REVIEWS

Specifications

FRAMEOrbea Occam OMR 140mm travel 29" C-Boost 12x148
SHOCKFox Float DPS Factory 3-Position Evol Kashima custom tune 210x50mm
FORKFox 34 Float Factory 140 FIT4 3-Pos-Adj QR15x110 Kashima
CRANKSETRace Face Next-R 32t
HEADSETAcros Alloy 1-1/8 - 1-1/2" Integrated
HANDLEBARRace Face Next R 35 20mm Rise 780mm
STEMRace Face Turbine R 35mm interface
SHIFTERSShimano XTR M9100
BRAKESShimano XTR M9120Hydraulic Disc
CASSETTEShimano XTR M9100 10-51t 12-Speed
REAR DERAILLEURShimano XTR M9100 SGS Shadow Plus
CHAINShimano CN-9100
WHEELSRace Face NEXT-SL TLR 15/110mm IS
TIRESMaxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR
TIRESMaxxis Rekon 2.40" FB 60 TPI Dual Exo TR
SEATPOSTFox Transfer Factory Kashima Dropper 31.6
SEATPOST LEVERShimano SL-MT-800 I-Spec EV
SADDLESelle Italia SLR Boost SuperFlow L Carbon Keramic Rail Ø7 x 9 mm
CHAINGUIDEOrbea OC chainguide

Geometry

SIZE S M L XL S-LT M-LT L-LT XL-LT
1. SEAT TUBE (C-T) 381 419 457 508 381 419 457 508
2. TOP TUBE (EFF) 565 592 619 649 565 592 619 649
3. HEAD TUBE 95 105 120 140 95 105 120 140
4. CHAINSTAY 440 440 440 440 440 440 440 440
5. BB HEIGHT 336 336 336 336 336 336 336 336
6. BB DROP 35 35 35 35 32 32 32 32
7. WHEELBASE 1165 1194 1224 1259 1165 1194 1224 1259
8. HEAD ANGLE 66º 66º 66º 66º 65.5º 65.5º 65.5º 65.5º
9. SEAT ANGLE 77º 77º 77º 77º 76.5º 76.5º 76.5º 76.5º
10. STANDOVER 710 736 766 776 710 736 766 776
11. REACH 425 450 474 500 425 450 474 500
12. STACK 604 613 627 646 604 613 627 646
13. FORK LENGTH 547 547 547 547 547 547 547 547
RAKE 44 44 44 44 44 44 44 44
