Product Description
The Colnago V3Rs Disc Frame is a masterpiece of modern engineering, designed to help you leave your competitors in the dust (or in this case, on the tarmac). This is the kind of frame that makes other bikes jealous - it's sleek, fast, and oh-so-pretty. It's like the Olympic sprinter of the bicycle world, ready to break records and hearts with its impressive speed and agility.
The V3Rs Disc Frame is made from high-quality carbon fiber, which is both lightweight and incredibly strong. This allows you to fly up hills and blast through corners with ease, all while feeling as light as a feather. The frame also features disc brakes, which provide excellent stopping power and control, even in wet or muddy conditions.
But this frame isn't just about speed and performance - it's also designed to be comfortable for long rides. The geometry of the frame is optimized for endurance, so you can ride all day without feeling fatigued. And with its beautiful paint job and signature Colnago branding, the V3Rs Disc Frame is sure to turn heads wherever you go.
In short, if you're looking for a frame that's as beautiful as it is fast, the Colnago V3Rs Disc Frame is the perfect choice. It's a work of art on two wheels, and it's ready to help you achieve your wildest cycling dreams.
REVIEWS
Specifications
Frame | Carbon monocoque |
Fork | 1-1/8" ~ 1-1/4" tapered straight blade carbon disc |
Rear Stay | Carbon |
Fork Axle | 12mm Thru x 100mm |
Headset Included | Yes, Colnago integrated |
Steerer Tube | 1 1/8” - 1 1/4” |
Bottom Bracket Type | TheadFit82.5 |
Cable Routing | Internal, electric or mechanical compatible |
Front Derailleur Mount | Braze-on |
Wheel Size | 700c |
Brake Type | Disc, flat mount |
Seatpost Diameter | Aero |
Seatpost Included | Yes |
Seat Collar Included | Yes |
Rear Axle | 12mm Thru x 142mm |
Sizes | 42cm | 45cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | |
Colors | RZWB, RZRD, RZBW, RZGR |
Weight | 780g |
Geometry
Size | Fork | Sc | A | C | Hs | Ss | bbdrop | O | Stack |
42s | 374 | 75.55 | 580 | 408 | 113 | 70.6 | 67 | 501 | 514 |
45s | 374 | 75.00 | 580 | 408 | 114 | 71 | 70 | 514 | 520 |
48s | 374 | 74.50 | 581 | 408 | 117 | 71.5 | 71 | 526 | 525 |
50s | 374 | 74.00 | 588 | 410 | 132 | 71.6 | 72 | 537 | 542 |
52s | 374 | 73.57 | 593 | 410 | 151 | 71.9 | 72 | 549 | 560 |
54s | 374 | 73.10 | 599 | 414 | 168 | 72.5 | 72 | 565 | 578 |
56s | 374 | 73.00 | 607 | 414 | 175 | 72.9 | 72 | 579 | 586 |
58s | 374 | 73.00 | 619 | 414 | 193 | 73.1 | 72 | 593 | 604 |
