SCOTT Spark RC Team
Product Details
The SCOTT Spark RC Team represents the ultimate evolution of the modern cross-country race bike, perfected geometry, increased 120mm travel front and rear, and world-class athlete input integrated into every detail. This is a race machine that refuses to choose between uphill efficiency and downhill confidence, delivering all-terrain performance for today’s fastest XC and marathon courses.
The Spark RC Carbon HMF frame features SCOTT’s Integrated Suspension Technology with a Flex Pivot design, creating exceptional stiffness, efficiency, and trail control in a remarkably clean package. Adjustable head angle geometry allows riders to fine-tune handling for different courses and preferences, while the Syncros Cable Integration System delivers a sleek cockpit with protected routing. Suspension duties are handled by a 120mm RockShox SID 3P fork and custom NUDE 5 RL3 shock, both controlled by SCOTT’s TwinLoc system, allowing instant switching between lockout, traction control, and full descend mode directly from the bars.
SRAM’s S1000 Eagle AXS Transmission provides wireless 12-speed shifting with a massive 10–52T range and precise, load-resistant gear changes, while SRAM DB6 4-piston brakes deliver confident stopping power. Rolling on Syncros Silverton 2.5-30 carbon wheels with Maxxis Rekon Race 29x2.4" tires, the Spark RC tips the scales at just 12.5kg tubeless, proof that advanced carbon engineering, suspension versatility, and wireless precision can coexist in a race-ready XC platform.
Key Features
- Frame - Spark RC Carbon HMF Frame
-
Suspension - RockShox SID 3P Air Fork with RockShox NUDE 5 RL3 Trunnion
custom tuned Shock - Drivetrian - SRAM S1000 Eagle AXS Transmission
- Wheelset - Syncros Silverton 2.5-30 CL
| Specification | Detail |
|---|---|
| Frame | Spark RC Carbon HMF, Integrated Suspension Technology, Flex Pivot, Adjustable head angle, Syncros Cable Integration System, BB92, UDH Interface, 12x148mm, 55mm Chainline |
| Fork | RockShox SID 3P Air, Rush RL 3-Mode Damper, 15x110mm Maxle Stealth, 44mm offset, Tapered steerer, Lockout, Rebound Adjust, 120mm travel |
| Rear Shock | RockShox NUDE 5 RL3 Trunnion, SCOTT custom with travel & geo adjustment, 3 modes (Lockout / Traction Control / Descend), DebonAir, Rebound Adjust, 120-80-Lockout, 165x45mm |
| Remote System | SCOTT TwinLoc Technology, Suspension & Dropper Remote, 3 Suspension modes |
| Rear Derailleur | SRAM S1000 Eagle AXS Transmission, 12-Speed, Wireless Electronic Shift System |
| Shifters | SRAM AXS Pod Controller |
| Crankset | SRAM Eagle 70 Transmission, DUB, 55mm Chainline, 34T |
| Chainguide | SCOTT custom |
| Bottom Bracket | SRAM DUB PF92 MTB Wide, shell 41x92mm |
| Chain | SRAM CN Eagle 70 Transmission |
| Cassette | SRAM Eagle XS-1270 V2 Transmission, 10-52 |
| Brakes | SRAM DB6 4-Piston Disc |
| Rotors | SRAM Centerline CL Rotors, 180mm front / 160mm rear |
| Handlebar | Syncros Fraser 2.0 XC Alloy 6061 D.B., Flat Bar, 8°, 740mm, Syncros Performance XC lock-on grips |
| Stem | Syncros XC 2.0, Syncros Cable Integration System, -12° rise, 6061 Alloy, 31.8mm, 1 1/8" |
| Seatpost | Syncros Duncan Dropper 1.5XC, 31.6mm, 100mm travel |
| Saddle | Syncros Belcarra V 2.0 Cut Out, CRMO rails |
| Headset | Syncros / Acros Angle Adjust & Cable Routing HS System, ±0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Wheelset | Syncros Silverton 2.5-30 CL, Front 15x110mm / Rear 12x148mm, 30mm tubeless-ready rim, 28H, Syncros axle with removable lever and integrated tools |
| Front Tire | Maxxis Rekon Race, 29x2.4", 120 TPI, Foldable Bead, Tubeless Ready, EXO |
| Rear Tire | Maxxis Rekon Race, 29x2.4", 120 TPI, Foldable Bead, Tubeless Ready, EXO |
| Extras | SRAM AXS Powerpack |
| Approx. Weight (kg) | 12.5 (Tubeless setup) |
| Approx. Weight (lbs) | 27.56 (Tubeless setup) |
| Max. System Weight | 130kg (includes bike, rider, equipment, and luggage) |
| Size | S | M | L | XL |
|---|---|---|---|---|
| Head Tube Angle | 67.2° | 67.2° | 67.2° | 67.2° |
| Head Tube Length (mm) | 90 | 90 | 105 | 115 |
| Top Tube (Horizontal, mm) | 562 | 590 | 614 | 642 |
| Standover Height (mm) | 758 | 765 | 776 | 799 |
| BB Drop (mm) | 45 | 45 | 45 | 45 |
| BB Height (mm) | 330 | 330 | 330 | 330 |
| Wheelbase (mm) | 1129 | 1159 | 1190 | 1231 |
| Seat Tube Length (mm) | 415 | 440 | 490 | 540 |
| Seat Tube Angle | 75.9° | 76.1° | 76.6° | 76.9° |
| Chainstay Length (mm) | 437.5 | 437.5 | 437.5 | 437.5 |
| Reach (mm) | 411 | 441 | 471 | 501 |
| Stack (mm) | 602.5 | 602.5 | 616 | 625 |
| Stem Length (mm) | 50 | 60 | 70 | 80 |
| Trail (mm) | 115 | 115 | 115 | 115 |
| Fork Length (mm) | 530 | 530 | 530 | 530 |
| Max Seatpost Insertion (mm) | 150 | 175 | 225 | 275 |
| Crank Length (mm) | 170 | 170 | 175 | 175 |
