OPEN WIDE Frameset With Contender Custom Paint
Product Details
This OPEN WIDE Frameset is a collaboration between OPEN and Contender Bicycles, featuring custom paint finishes available in limited quantities only available at Contender. This frameset showcases the proven WIDE platform with distinctive colorways, offering riders a combination of performance and design.
Built for riders who look for detours and want versatility without compromising speed, the WI.DE. is built to handle more extreme terrain, while maintaining the efficient geometry that makes OPEN frames legendary.
With the largest tire clearance in OPEN’s lineup, the WI.DE. fits up to 2.4" (61mm) tires on 650b wheels or 46mm on 700c wheels, transforming rough trails, roots, and rocks into manageable terrain. Its innovative double-drop chainstays create a box shape behind the bottom bracket, increasing stiffness, reducing weight, and maximizing clearance without compromising fast road geometry.
Additional engineering details reinforce the WI.DE.’s performance edge: Wire-stays provide vertical compliance while maintaining lateral stiffness, the Flat-Out downtube strategically applies ultra-high modulus carbon for stiffness, and the zero-setback seattube angle ensures efficient positioning for most riders. All of this comes in at just 1040 grams, the same as the U.P., proving that maximum tire clearance doesn’t mean performance compromises.
Perfect for riders who prioritize versitility, this limited Contender edition is equally at home on technical mountain bike trails with 27.5" tires or lightning-fast gravel roads with 700c wheels. The OPEN WIDE Frameset is a blank canvas with limitless potential to create the ultimate custom build of your dreams.
Key Features
- Frame: OPEN carbon construction with double-drop chainstays.
- Tire Clearance: 2.4" With 650b or 46mm with 700c.
- Exclusive Paint job: Limited Contender Bicycles Edition with custom paint finishes.
| Component | Specification |
|---|---|
| Weight Frame-only (Size M, w/o metal parts ±3%) | 1040g |
| Weight Fork-only (±3%) | 390g |
| BB Standard | BB386EVO pressfit 86.5x46mm BB shell |
| Recommended Groupsets | Dedicated 1x (2x only with Classified hub). Recommended: Shimano GRX, SRAM AXS (except Transmission), older SRAM 1x mechanical, Campagnolo Ekar |
| Shimano Crank Fit | All road cranks |
| SRAM Crank Fit | All DUB road, Force 1 BB30 |
| Front Derailleur Mount | None (1x standard, 2x only with Classified hub) |
| Maximum 1x Ring Size | 46t flat (check compatibility), 42t SRAM offset (clearance depends on chainline/chainring) |
| Minimum 1x Ring Size | 38t (flat & offset). Smaller possible depending on cassette/derailleur/chain setup |
| Front Thru-Axle | 100x12mm superlight Carbon-Ti X-12 |
| Front Disc Rotor Size | 160mm only |
| Front Brake Caliper Mount | Smartmount 160 (flatmount caliper, no adaptor) |
| Rear Thru-Axle | 142x12mm superlight Carbon-Ti X-12 |
| Rear Disc Rotor Size | 160mm only |
| Rear Brake Caliper Mount | Smartmount 160 (flatmount caliper, no adaptor) |
| MultiStop Internal System | Mechanical 1x, Di2, eTap |
| Headset | Integrated IS42/28.6 | IS52/40 (45x45° lower bearing). Compatible with Cane Creek BAA1131 (upper), BAA1161 (lower), Chris King DropSet 2, Token Omega A83 |
| Seatpost | 27.2mm diameter, zero-offset (standard setup) |
| Fenders | Compatible with OPEN De-fender or clip-on (e.g. SKS Speedrocker) |
| Cage Mounts | Seattube, downtube, under-downtube, under-BB |
| TT Bag Mount | 100mm front-post-to-headset-edge |
| Max Weight (Rider + Luggage) | 120kg / 264 lbs |
| Standards | EN/ISO/internal test standard |
| Included with Frameset | Headset, seattube top clamp, rail clamp, thru-axles, 2 RD hangers, 2 MultiStops (1x, Di2, eTap), cable exit stop, noise-reduction foam sleeves, bottle cage bolts, manual |
| Component | SRAM Rival / GX AXS Eagle 1x12 Mullet | Sram Force / XX1 AXS Eagle 1x12 Mullet | Shimano GRX / XTR Di2 1x12 |
|---|---|---|---|
| Levers/Calipers | SRAM Rival AXS E1 Shifter / Brake Lever and Caliper | SRAM Force AXS E1 Shifter / Brake Lever and Caliper | Shimano GRX ST-RX825 Shift Lever and Caliper |
| Crankset | SRAM Rival E1 | SRAM Force E1 | Shimano GRX FC-RX820-1, 1x 12 |
| Front Derailleur | NA | NA | NA |
| Rear Derailleur | SRAM GX AXS Eagle | SRAM XX1 AXS Eagle | Shimano XTR RD-M9250-SGS |
| Chain | SRAM GX Eagle | SRAM X01 EAGLE | Shimano XT CN-M8100 |
| Cassette | SRAM GX Eagle 10/52t | SRAM X01 Eagle 10/52t | Shimano XTR CS-M9200 10/51t |
| Rotors | SRAM Paceline | SRAM Paceline | Shimano RT-CL900 |
| Battery/Extras | Batt/Charger | Batt/Charger | Battery/Wires/Charger |
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Common Rider Height (cm) | < 165 | 160-171 | 169-180 | 178-191 | 188-205 |
| Stack | 520 | 545 | 570 | 595 | 620 |
| Reach | 346 | 358 | 370 | 382 | 394 |
| Head Tube Length | 99 | 125 | 150 | 170 | 196 |
| Fork Offset | 50 | 50 | 50 | 50 | 50 |
| Standover (tire size dependent) | 707 | 739 | 777 | 794 | 817 |
| Head Tube Angle | 68° | 69° | 71° | 71.5° | 71.5° |
| Seat Tube Length | 464 | 495 | 530 | 550 | 564 |
| Seat Tube Angle | 74.5° | 74.0° | 73.5° | 73.5° | 73.5° |
| Top Tube Length (Horizontal) | 510 | 530 | 550 | 570 | 590 |
| BB Drop | 80 | 77 | 75 | 75 | 75 |
| Front Center | 583 | 596 | 599 | 613 | 634 |
| Top Tube Length (Norm.) | 490 | 515 | 540 | 560 | 580 |
| Rear Center | 420 | 420 | 420 | 420 | 420 |
| Wheelbase | 990 | 1004 | 1009 | 1022 | 1042 |
