OPEN WIDE 2.0 Frameset
Product Details
The OPEN WI.DE. 2.0 Frameset is engineered for riders who refuse to define where the road ends. Built to be the fastest solution on the roughest terrain imaginable, it combines aero efficiency, gravel capability, and expedition-ready versatility into a single uncompromising platform. From ultra-distance racing to remote bikepacking adventures, this is a frameset designed to perform where others simply cannot.
At its core, the WI.DE. 2.0 delivers extraordinary capability through massive tire clearance up to 700x66mm (29x2.6”), unlocking unprecedented grip, comfort, and control on the most demanding surfaces. This extreme volume allows lower pressures for improved traction and stability, while preserving the bike’s signature road-like speed and responsiveness through OPEN’s refined A.I.R. geometry (Agile, Integrated, Refined).
The innovative U-Turn AC/DC+ fork blends aerodynamic shaping with integrated cargo capability, allowing riders to carry gear directly on the fork or through modular mounting systems without compromising performance. Across the frame, integrated storage options, multiple cargo mounts, and frame bag compatibility create a true expedition-ready system, while the downtube storage with Fidlock closure keeps essentials secure and accessible.
Engineered in Portugal under OPEN’s “Made in Freedom” philosophy, the WI.DE. 2.0 pairs advanced carbon construction with thoughtful functional design, including a double-dropped chainstay layout for maximum clearance and stiffness. The result is a frameset that remains fast, agile, and composed even in the harshest environments, delivering speed where terrain would normally dictate otherwise.
Key Features
- Frame - OPEN WI.DE. 2.0 Carbon Frameset: Ultra-high clearance up to 700x66mm (29x2.6”) for extreme terrain capability
- Geometry - Agile, road-inspired handling with stability for technical and loaded riding
- Fork - U-Turn AC/DC+ Fork: Aerodynamic design with integrated cargo mounting capability
- Storage & Mounts - Integrated downtube storage (Fidlock) plus multiple cargo and frame bag mounting options
| Specification | Detail |
|---|---|
| Frame Weight | 875g (Raw-Ready-To-Paint, ±3%) |
| Frame / Fork / Stem-Bar Sizes | Frame: XS/S/M/L/XL; Fork: XS/S/M/L/XL; Stem-Bar: 60–130mm length, 380–430mm width |
| Fork / Stem Compatibility | Only compatible with OPEN U-Turn AC/DC+ fork and OPEN length-adjustable B.A.R. system |
| Stock Colors | Platinum grey/greige; Raw-Ready-To-Paint (RRTP) |
| RRTP Notes | Clearcoat not required for UV protection, but recommended for scratch resistance; frame can be left raw or custom painted |
| Recommended Groupsets | SRAM AXS; Shimano GRX Di2; Campagnolo Super Record 13 (with nano clutch options depending on cassette range) |
| Recommended Tire Sizes | Optimized for 50–66mm tires (700c); recommended 55–66mm tires with ≥28mm internal width rims for best performance |
| Bottom Bracket Standard | T47 threaded, 85.5mm shell width (internal cups) |
| BB Compatibility Note | Designed for 85.5mm shells; 86.5mm BBs can be used with 0.5mm spacers per side |
| Max Chainring Sizes | Shimano GRX 1x: 46T; SRAM AXS 1x: 46T; Campagnolo 1x: 46T (oval rings may vary fit by ~2T equivalent) |
| Axles | Front: 100x12mm Carbon-Ti X-12; Rear: 142x12mm Carbon-Ti X-12 |
| Brake System | 160mm rotor only, Smartmount 160 flatmount caliper system (no adaptor required) |
| Chain Catcher | Custom low-mount Wolftooth chain catcher (not cross-compatible with other OPEN models) |
| Headset | IS52/40 45° x 45° upper & lower bearing standard |
| Seatpost | 27.2mm round, compatible with dropper and suspension seatposts |
| Computer Mount | Integrated mount compatible with Garmin, Wahoo, Hammerhead; GoPro-compatible underside mount |
| Indoor Trainer Compatibility | Compatible with direct drive trainers (e.g. Wahoo KICKR, Elite Justo, Tacx Neo series); adaptor may be required depending on setup |
| Max System Weight | 120kg / 264 lbs (rider + luggage) |
| Included With Frameset | Frame, fork, headset, integrated handlebar, UDH hanger, noise-reduction foam sleeves, bottle cage bolts, manual |
| Measurement | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Stack (mm) | 540 | 565 | 590 | 615 | 640 |
| Reach (mm) | 349 | 361 | 374 | 386 | 398 |
| Seat Tube Length (mm) | 417 | 449 | 480 | 504 | 518 |
| Top Tube Length (mm) | 487 | 508 | 528 | 548 | 567 |
| Seat Tube Angle (°) | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Head Tube Angle (°) | 69.0° | 70.5° | 70.5° | 71.5° | 71.5° |
| Bottom Bracket Drop (mm) | 96 | 91 | 88 | 87 | 86 |
| Front Center (mm) | 607 | 608 | 630 | 633 | 653 |
| Rear Center (mm) | 440 | 440 | 440 | 440 | 440 |
| Wheelbase (mm) | 1029 | 1032 | 1055 | 1058 | 1079 |
| Standover Height (mm) | 718 | 750 | 781 | 804 | 819 |
| Approx. Rider Height (cm) | < 165 | 160–171 | 169–180 | 178–191 | > 188 |
| Approx. Rider Height (in) | < 5'5" | 5'3"–5'8" | 5'6"–5'11" | 5'10"–6'3" | > 6'2" |
