Product Details
The Orbea Wild ST H30 20MPH is "The Yes Machine". Welcome to a world beyond power where far and fast is taken for granted. Whatever question the trail poses, the answer is always yes. Built without compromises, this lightweight and fully optimized electric mountain bike leaves the factory ready for action with the latest Bosch motor and race-ready components that deliver trail power for riders who want Wild's award-winning performance in a more accessible package.
Built around Orbea's acclaimed Wild Hydro frame in high-polish alloy construction, the Wild ST features 150mm of trail-optimized suspension front and rear that's perfectly tuned for varied terrain. The gravity-oriented geometry delivers stability and confidence at speed while maintaining the playful, involving character that makes Wild feel alive rather than detached like many electric bikes. Advanced frame construction and e-optimized rigidity ensure this bike handles the additional forces of electric assistance without excess weight.
The Bosch Performance Line CX motor provides nearly silent operation with precise control and endless power, paired with the substantial 600Wh Powertube battery for incredible range on the longest adventures. The integrated Kiox 400C display seamlessly mounts in the frame with USB-C charging, customizable layouts, and built-in navigation. Shimano Deore M6100 12-speed drivetrain delivers reliable shifting performance, while the alloy tubeless-ready 29" wheelset maximizes stability and control across technical terrain.
Perfect for riders seeking trail-focused performance with full electric mountain bike capability, the Wild ST H30 transforms climbs and descents with optimized weight distribution, clean cable routing, and ergonomic details that enhance every ride. This is performance through simplicity, removing anything unnecessary while adding only what directly improves the experience on the wildest trails.
Key Features
- Frame – Orbea Wild Hydro High Polish Alloy with 29" Wheel Compatibility
- Suspension – RockShox Psylo Silver RC Fork and Fox Float Performance Custom Tune Shock (150mm)
- Motor – Bosch Performance Line CX
- Battery- Bosch Powertube 600Wh Battery
- Drivetrain – Shimano Deore M6100 12-Speed with MT420 Hydraulic Disc Brakes
- Wheelset – Alloy Tubeless Ready 29"
| Specification | Detail |
|---|---|
| Frame | Orbea Wild Hydro, 29" wheels, Concentric Boost 12x148 |
| Shock | Fox Float Performance Trunion 2-Pos Evol LV custom tune 205x57.5mm |
| Fork | RockShox Psylo Silver RC 15x110 Boost |
| Steerer Tube | Alloy 1-1/2", Black Oxidated Bearing |
| Battery | Bosch Powertube 600Wh Horizontal BBP3865 |
| Range Extender | N/A |
| Motor | Bosch Performance Line CX BDU3843 |
| Display | Bosch System Controller BRC3100 |
| Charger | Bosch Charger 2A (100-120V) |
| Remote | Bosch Mini Remote BRC3300 |
| Chainring | Steel 32T |
| Crank | Prowheel EB17 Alloy |
| Shifters | Shimano Deore M6100 I-Spec EV |
| Cassette | Shimano CS-M6100 10-51T, 12-Speed |
| Rear Derailleur | Shimano Deore M6100 SGS Shadow Plus |
| Chain | Shimano M6100 |
| Chainguide | e*thirteen Plus Bosch CX Gen4 CL 55 32-36T |
| Handlebar | OC Mountain Control MC30, Rise20, Width 800 |
| Stem | OC Mountain Control MC20, 0º |
| Computer Mount | OC Computer Mount CM-05, Garmin/Sigma |
| Brakes | Shimano MT420 Hydraulic Disc |
| Rotors | Shimano SMRT30, 203mm Front / 203mm Rear |
| Wheels | Alloy, Tubeless, 29", 29c, 32H |
| Front Tire | Maxxis Minion DHF 2.50", 60TPI, Rigid EXO/TR |
| Rear Tire | Maxxis Dissector 2.40", 60TPI, Rigid EXO/TR |
| Seatpost | OC Mountain Control MC22, 31.6mm, Dropper |
| Seatpost Lever | Shimano SL-MT500 I-Spec EV |
| Saddle | Selle Royal Vivo Sport Men, 145 x 269mm |
| Grips | OC Lock On |
| Lights | N/A |
| Size | S | M | L | XL |
|---|---|---|---|---|
| Seat Tube (C-T) | 415 | 415 | 435 | 450 |
| Top Tube (EFF) | 561 | 583 | 610 | 636 |
| Head Tube | 110 | 120 | 130 | 140 |
| Chainstay | 448 | 448 | 448 | 448 |
| BB Drop | 28 | 28 | 28 | 28 |
| BB Height | 352 | 352 | 352 | 352 |
| Wheelbase | 1219 | 1243 | 1273 | 1302 |
| Head Angle | 64,5 | 64,5 | 64,5 | 64,5 |
| Seat Angle | 78,4 | 78,4 | 78,4 | 78,4 |
| Rake | 44 | 44 | 44 | 44 |
| Standover | 720 | 720 | 720 | 720 |
| Reach | 440 | 460 | 485 | 509 |
| Stack | 619 | 628 | 637 | 645 |
| Fork Length | 565 | 565 | 565 | 565 |
