Product Details
*Please note that bike specifications are subject to change without prior notice |
Frame: | Roadmachine 01 AMP Premium Carbon with Tuned Compliance Concept Endurance | Integrated Battery | Integrated Rear Light | Internal Cable Routing | ICS Technology Stealth Cable Routing | Fender Mounts | Flat Mount Disc | 12x142mm Thru-Axle |
---|---|
Fork: | Roadmachine 01 AMP Premium Carbon with Tuned Compliance Concept Endurance | Flat Mount Disc | 12x100mm Thru-Axle |
Handlebar: | BMC RAB 02, Ergo Top Shape, Compact Bend |
Stem: | BMC ICS2 - Integrated Cockpit Design |
Seatpost: | Roadmachine 01 AMP Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible |
Saddle: | Fizik Argo Tempo R5 (150mm) |
Gears: | 2x11 |
Crankset: | Rotor eVegast 48-31T |
Cassette: | SHIMANO CS-HG800 11-34T 11 speed |
Chain: | SHIMANO HG-601 11 spd |
Front Derailleur: | SHIMANO GRX Di2 FD-RX815 |
Rear Derailleur: | SHIMANO GRX Di2 RD-RX817 11spd |
Shifters: | SHIMANO GRX Di2 ST-RX815 11spd |
Brake Levers / Calipers: | SHIMANO GRX BR-RX810 |
Rotors: | SHIMANO RT-MT800 180 mm / RT-EM810 180 mm - Centerlock |
Rims: | CRD-400 Carbon - Tubeless Ready - 40mm |
Hubs (F/R): | CRD-400 |
Tires: | Pirelli Cinturato Velo TLR, 32mm |
Drive Unit: | TQ-HPR50 Drive Unit |
Battery Pack: | TQ 360 Wh Battery |
Display: | TQ Display | 2" O-LED | Bluetooth / ANT+ |
Charger: | TQ HPR-50 4A Charger |
Accessories: | Integrated Rear Light |
Tire Clearance: | 38mm (Measured Width) |
ASTM Classification: | Level 2 |
Weight Limit: | 120 Kg |
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height | <162 | 162-174 | 172-180 | 178-186 | 184-192 | >190 |
Reach | 370 | 379 | 383 | 388 | 393 | 398 |
Stack | 525 | 550 | 570 | 595 | 620 | 645 |
Bar Drop | 125 | 125 | 125 | 125 | 125 | 125 |
Bar Reach | 70 | 70 | 70 | 70 | 70 | 70 |
Bar Width | 400 | 420 | 420 | 420 | 420 | 440 |
BB Drop | 75 | 75 | 75 | 75 | 75 | 75 |
Crank Length | 170 | 170 | 170 | 170 | 170 | 170 |
Fork Length | 380 | 380 | 380 | 380 | 380 | 380 |
Fork Rake | 50 | 50 | 45 | 45 | 45 | 45 |
Front Center | 579 | 596 | 594 | 607 | 620 | 633 |
Head Tube | 112 | 138 | 154 | 181 | 207 | 233 |
Head Tube Angle | 71.4 | 71.4 | 72.2 | 72.2 | 72.2 | 72.2 |
Rear Center | 420 | 420 | 420 | 420 | 420 | 420 |
Seat Angle | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
Seat Tube | 420 | 460 | 500 | 525 | 545 | 575 |
Seatpost Length | 230 | 280 | 280 | 280 | 280 | 330 |
Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
Standover Height | 728 | 755 | 786 | 810 | 829 | 850 |
Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
Stem Length | 90 | 90 | 100 | 110 | 110 | 110 |
Top Tube | 519 | 535 | 544 | 556 | 568 | 581 |
Trail | 63 | 63 | 63 | 63 | 63 | 63 |
Wheelbase | 987 | 1005 | 1002 | 1015 | 1028 | 1041 |
