Product Details
The SCOTT Scale 910 represents a whole new breed in the world of hardtail mountain bikes, balancing racing-inspired geometry with straightforward, sharp design that proudly flaunts its definitive characteristics. Built on SCOTT's pursuit of perfection and drive for pure efficiency, the Scale line strictly follows the guiding principle of "Form follows Function," centering the design around the essentials to create an XC bike with distinctive character and an aggressive look that's ready for just about anything.
Crafted with SCOTT's Scale Carbon HMF frame construction, the 910 delivers the perfect combination of lightweight performance and race-ready stiffness that defines the Scale platform. This uncompromising approach to design eliminates unnecessary elements while maintaining the bike's DNA, resulting in a clear, focused package that excels in technical cross-country racing and fast, punchy singletrack where efficiency matters most.
The FOX 32 Float Rhythm fork with 110mm of travel provides controlled suspension performance that balances weight savings with capable handling across varied terrain. Paired with SRAM Eagle 70 Transmission 12-speed wireless shifting, the drivetrain delivers precise, reliable gear changes with the simplified maintenance and instant response that electronic systems provide. The Syncros X-30SE TR tubeless-ready wheelset completes the package with dependable performance and quick engagement.
Perfect for riders seeking a race-capable hardtail that combines SCOTT's carbon expertise with modern component technology, the Scale 910 delivers the ultimate yet most simple construction for XC performance. This is a bike that proudly shows off its characteristics with straightforward design and aggressive capability for those ready to answer the challenge.
Key Features
- Frame - Scale Carbon HMF Construction
- Suspension - FOX 32 Float Rhythm 110mm Fork
- Drivetrain - SRAM Eagle 70 Transmission 12-Speed Wireless
- Wheelset - Syncros X-30SE TR Tubeless Ready
| Specification | Detail |
|---|---|
| Frame | Scale Carbon HMF, Adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92, UDH Interface, 12x148mm with 55mm Chainline |
| Fork | FOX 32 Float Rhythm Grip, 3-Modes, 15x110mm QR axle, 44mm offset, tapered steerer, Reb. Adj., Lockout, 110mm travel |
| Remote System | SCOTT RideLoc Technology, Suspension & Dropper Remote, 3 Suspension modes |
| Rear Derailleur | SRAM Eagle 70 Transmission, 12 Speed |
| Shifters | SRAM Eagle 70 Trigger |
| Crankset | SRAM Eagle 70 Transmission, DUB, 55mm CL, 32T |
| Chainguide | SCOTT custom |
| Bottom Bracket | SRAM DUB PF 92 MTB Wide, shell 41x92mm |
| Chain | SRAM CN Eagle 70 Transmission |
| Cassette | SRAM Eagle XS 1270 V2 Transmission, 10-52T |
| Brakes | Shimano MT401 Disc |
| Rotors | Shimano SM-RT10 CL, 180mm front / 160mm rear |
| Handlebar | Syncros Alloy 6061, T-shape Flat, 9°, 740mm, with Syncros Performance XC lock-on grips |
| Stem | Syncros DC 3.0, Syncros Cable Integration System, 0° rise, 6061 Alloy, 31.8mm, 1 1/8" |
| Seatpost | Syncros Duncan Dropper, 31.6mm, S size 100mm, M size 130mm, L & XL size 150mm |
| Seat | Syncros Belcarra Regular 2.5 |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Front Hub | Formula CL-811, 15x110mm |
| Rear Hub | Formula CL-3248, 12x148mm |
| Spokes | Stainless Black 15G, 1.8mm |
| Rims | Syncros X-30SE, 32H, 30mm, Tubeless ready |
| Front Tire | Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead, EXO, Tubeless Ready |
| Rear Tire | Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead, EXO, Tubeless Ready |
| Approx. Weight | 11.9 kg (Tubeless setup) |
| Approx. Weight | 26.23 lbs (Tubeless setup) |
| Max. System Weight | 130kg |
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Head Tube Angle | 67.9° | 67.9° | 67.9° | 67.9° |
| Head Tube Length (mm) | 90.0 | 95.0 | 110.0 | 120.0 |
| Top Tube Horizontal (mm) | 575.0 | 600.2 | 626.0 | 656.5 |
| Standover Height (mm) | 752.0 | 781.0 | 800.0 | 835.1 |
| BB Offset (mm) | -62.0 | -62.0 | -62.0 | -62.0 |
| BB Height (mm) | 313.0 | 313.0 | 313.0 | 313.0 |
| Wheelbase (mm) | 1105.4 | 1131.1 | 1158.0 | 1189.4 |
| BB Center to Top of Seat Tube (mm) | 390.0 | 440.0 | 480.0 | 530.0 |
| Seat Angle | 75.4° | 75.4° | 75.3° | 75.3° |
| Chainstay (mm) | 425.0 | 425.0 | 425.0 | 425.0 |
| Reach (mm) | 418.5 | 442.3 | 463.6 | 491.2 |
| Stack (mm) | 600.3 | 604.9 | 618.9 | 628.1 |
| Stem Length (mm) | 50.0 | 60.0 | 70.0 | 80.0 |
| Trail (mm) | 105.0 | 105.0 | 105.0 | 105.0 |
| Fork Length (mm) | 506.0 | 506.0 | 506.0 | 506.0 |
| Maximum Seatpost Insertion (mm) | 160.0 | 210.0 | 250.0 | 300.0 |
| Crank Length (mm) | 170.0 | 170.0 | 175.0 | 175.0 |
