SCOTT Scale Gravel RC
Product Details
The SCOTT Scale Gravel RC was designed for going on adventures with attitude, engineered to go the distance over any and all types of terrain with lightweight construction and agile handling. This high-performance gravel bike combines SCOTT's advanced carbon expertise with practical adventure-ready features, delivering a platform that's as capable on remote backroads as it is confident on technical gravel sectors. Multiple mounting options ensure readiness for bikepacking missions or all-day explorations wherever the route leads.
Built using revolutionary monocoque construction, the Scale Carbon HMF frame enables production with only one mold for the entire front triangle. Applying SCOTT's carbon expertise, the frame consists of just three separate pieces molded together, directly translating into increased efficiency through reduced junction points. This approach decreases weight while maintaining superior stiffness—the hallmark of SCOTT's race-proven engineering. The monocoque design enables the frame to handle forces as a unified system for optimal performance.
Innovative details set the Scale Gravel RC apart from conventional gravel bikes. The service door accessible through the downtube cover allows easy interior frame access without removing the bottom bracket, making cable routing maintenance simple and straightforward. The advanced hollow dropout construction allows the axle head to clamp against the inner dropout surface while sitting flush with the exterior, enabling the lightest possible construction with a clean aesthetic. This optimized design shaves 7.5g from the dropouts alone while favoring a narrower rear triangle construction that reduces an additional 20g in the HMX-SL frame area.
Perfect for riders seeking lightweight gravel performance with adventure versatility, the Scale Gravel RC pairs its advanced carbon platform with SRAM X0 AXS Transmission wireless electronic shifting with integrated power meter and the tubeless-ready Syncros Silverton GR TR wheelset. This is gravel riding reimagined for those who refuse to compromise between race-day speed and expedition-ready capability.
Key Features
- Frame - Scale Carbon HMF Monocoque Construction Frame and Fork
- Drivetrain - SRAM X0 AXS Transmission Wireless with Power Meter
- Wheelset - Syncros Silverton GR TR Tubeless Ready
| Specification | Detail |
|---|---|
| Frame | Scale Carbon HMF, Adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92, UDH Interface, 12x148mm with 55mm Chainline |
| Fork | Scale Rigid HMF, Postmount Disc Standard, Tapered Carbon steerer |
| Rear Derailleur | SRAM X0 Eagle AXS Transmission 12-Speed, Wireless Electronic Shift System |
| Shifters | SRAM AXS Rocker Pod Controller |
| Crankset | SRAM X0 Eagle Transmission, Spindle Power Meter, DUB, 55mm Chainline, 34T |
| Chainguide | SCOTT custom |
| Bottom Bracket | SRAM DUB PF92 MTB Wide, shell 41x92mm |
| Chain | SRAM CN X0 Eagle Transmission |
| Cassette | SRAM X0 Eagle XS 1295 Transmission, 10-52 |
| Brakes | SRAM Motive Silver 4-Piston Disc |
| Rotors | SRAM HS2 CL Rotors, 180mm front / 160mm rear |
| Handlebar | Syncros Fraser iC SL XC Carbon, -20° rise, 8° backsweep, 740mm |
| Grips | Syncros Performance XC lock-on grips |
| Seatpost | Syncros Duncan 1.0 Carbon, 10mm offset, 31.6x400mm |
| Saddle | Syncros Belcarra V2.0 Cut Out, CRMO rails |
| Headset | Syncros / Acros Angle adjust & Cable Routing HS System, ±0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Wheelset | Syncros Silverton 1.0X CL, Carbon rims, Tubeless ready, 28H, XD Driver, F: 15x110mm / R: 12x148mm |
| Front Tire | Schwalbe Thunder Burt 29x2.35” EVO, Super Ground, TLE, 67EPI, Addix Speed |
| Rear Tire | Schwalbe Thunder Burt 29x2.35” EVO, Super Ground, TLE, 67EPI, Addix Speed |
| Extras | SRAM AXS Powerpack |
| Accessories | Spirgrips+ Inner Bar Ends, Milkit Tire Sealant |
| Approx. Weight (kg) | 9.1 (Tubeless setup) |
| Approx. Weight (lbs) | 20.06 (Tubeless setup) |
| Max. System Weight | 120kg (Includes bike, rider, equipment, and luggage) |
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Head Tube Angle | 67.9° | 67.9° | 67.9° | 67.9° |
| Head Tube Length (mm) | 90.0 mm | 95.0 mm | 110.0 mm | 120.0 mm |
| Top Tube Horizontal (mm) | 575.0 mm | 600.2 mm | 626.0 mm | 656.5 mm |
| Standover Height (mm) | 752.0 mm | 781.0 mm | 800.0 mm | 835.1 mm |
| BB Offset (mm) | -62.0 mm | -62.0 mm | -62.0 mm | -62.0 mm |
| BB Height (mm) | 313.0 mm | 313.0 mm | 313.0 mm | 313.0 mm |
| Wheelbase (mm) | 1105.4 mm | 1131.1 mm | 1158.0 mm | 1189.4 mm |
| BB Center to Top of Seat Tube (mm) | 390.0 mm | 440.0 mm | 480.0 mm | 530.0 mm |
| Seat Angle | 75.4° | 75.4° | 75.3° | 75.3° |
| Chainstay (mm) | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm |
| Reach (mm) | 418.5 mm | 442.3 mm | 463.6 mm | 491.2 mm |
| Stack (mm) | 600.3 mm | 604.9 mm | 618.9 mm | 628.1 mm |
| Stem Length (mm) | 50.0 mm | 60.0 mm | 70.0 mm | 80.0 mm |
| Trail (mm) | 105.0 mm | 105.0 mm | 105.0 mm | 105.0 mm |
| Fork Length (mm) | 506.0 mm | 506.0 mm | 506.0 mm | 506.0 mm |
| Maximum Seatpost Insertion (mm) | 160.0 mm | 210.0 mm | 250.0 mm | 300.0 mm |
| Crank Length (mm) | 170.0 mm | 170.0 mm | 175.0 mm | 175.0 mm |
