Colnago C68 Road Disc Frameset
Request Info
Colnago C68 Road Disc Frameset
Product Details
The Colnago C68 Road Disc Frameset represents the pinnacle of Italian craftsmanship and engineering for serious road cyclists who demand maximum stiffness, power transfer, and unmistakable style. This high-end frameset combines Colnago's legendary heritage with modern performance technology, delivering a responsive and exhilarating ride that stands ready to dominate on any road, whether attacking steep climbs, launching sprints, or pushing pace on long efforts.
Built with full carbon construction across the frame, fork, and seatpost, the C68 minimizes weight while providing exceptional stiffness and responsiveness that serious riders demand. The oversized downtube and bottom bracket create maximum power transfer and efficiency, especially during high-intensity efforts where every watt counts. Strategic tube shaping throughout the frameset ensures that power flows directly from pedals to pavement without flex or energy loss, translating rider effort into forward momentum with incredible efficiency.
Aerodynamic refinement enhances the C68's performance profile through the aero-shaped seat tube and seatpost design that reduces wind resistance and improves overall speed and efficiency. Clean internal cable routing creates a streamlined aesthetic while protecting cables from the elements, complemented by an integrated seat clamp that reduces weight and further improves aerodynamics. Every detail reflects Colnago's commitment to creating framesets that perform at the highest level while maintaining the distinctive character that has made the brand iconic.
Perfect for riders seeking top-of-the-line performance with Italian racing pedigree, the Colnago C68 Road Disc Frameset delivers the ultimate combination of efficiency, responsiveness, and timeless style. This is the frameset for building a dream machine that honors Colnago's storied racing heritage while embracing modern disc brake technology and performance standards.
Key Features
- Frame - Full Carbon Construction with Oversized Downtube and Bottom Bracket
- Fork - Full Carbon with Disc Brake Compatibility
- Aerodynamics - Aero-Shaped Seat Tube and Seatpost Design
| Specification | Detail |
|---|---|
| Series | C Series |
| Model | C68 Road |
| Weight | Size 485 unpainted frame: 925g |
| Weight Limit | 120 kg (combined bike, rider, and load) |
| Frame | Modular carbon frame construction: 8 carbon parts |
| Fork | Carbon fork for disc brakes, integrated cables, 1"1/8 section |
| Headset | ID:35 OD:47 36°/45° CeramicSpeed SLT Treated Bearings |
| Seatpost | Carbon seatpost, 0.15 offset, "D-Shape" section |
| Through Axles | Diameter: 12 mm; Length: 100 mm (Front) / 142 mm (Rear) |
| Measurement | 420 | 455 | 485 | 510 | 520 | 550 | 570 |
|---|---|---|---|---|---|---|---|
| Fork Length (mm) | 379 | 379 | 379 | 379 | 379 | 379 | 379 |
| Seat Tube Angle (°) | 75.5 | 75 | 74.5 | 74 | 73.5 | 73 | 73 |
| Front Center (mm) | 576 | 582 | 591 | 599 | 605 | 614.5 | 625 |
| Chainstay Length (mm) | 408 | 408 | 408 | 410 | 414 | 414 | 414 |
| Head Tube Length (mm) | 103 | 114 | 130 | 148 | 164 | 181 | 200 |
| Head Tube Angle (°) | 70.6 | 71 | 71.5 | 71.8 | 72.5 | 72.9 | 73.1 |
| Bottom Bracket Drop (mm) | 72 | 72 | 72 | 72 | 72 | 72 | 72 |
| Effective Top Tube (mm) | 504 | 517 | 535 | 550 | 567 | 586 | 599 |
| Stack (mm) | 510 | 522 | 539 | 557 | 575 | 593 | 612 |
| Reach (mm) | 370 | 375 | 383 | 388 | 395 | 403 | 410 |
| *Please note that bike specifications are subject to change without prior notice |
| Build | Price |
| C68 Campy SR EPS Disc, Campy Bora ULTRA WTO 45 DB | $18,099.95 |
| C68 Campy SR EPS Disc, Fulcrum Racing Wind 400 DB | $15,199.95 |
| C68 Campy SR EPS Disc, Fulcrum Racing 600 DB | $13,999.95 |
| C68 Dura Ace R9270 Di2 Disc, Zipp 303 Firecrest | $16,199.95 |
| C68 Dura Ace R9270 Di2 Disc, Dura Ace WHR9270 | $15,999.95 |
| C68 Dura Ace R9270 Di2 Disc, Fulcrum Racing Wind 400 DB | $14,799.95 |
| C68 Dura Ace R9270 Di2 Disc, Fulcrum Racing 600 DB | $13,699.95 |
| C68 Ultegra R8170 Di2 Disc, Fulcrum Racing Wind 400 DB | $11,199.95 |
| C68 Ultegra R8170 Di2 Disc, Fulcrum Racing 600 DB | $10,099.95 |
| C68 RED eTap AXS Disc, Zipp 303 Firecrest | $15,299.95 |
| C68 RED eTap AXS Disc, Fulcrum Racing Wind 400 DB | $13,799.95 |
| C68 RED eTap AXS Disc, Fulcrum Racing 600 DB | $12,799.95 |
| C68 Force eTap AXS Disc, Fulcrum Racing Wind 400 DB | $10,899.95 |
| C68 Force eTap AXS Disc, Fulcrum Racing 600 DB | $9,799.95 |
| Additional | Price |
| CC.01 Integrated Handlebar | $964.95 |
| Color Configurator Studio - available for complete bicycles only | $1,299.95 |
