SCOTT Scale Gravel 10
Product Details
The SCOTT Scale Gravel 10 was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, this lightweight gravel bike combines agile handling with multiple mounting options for versatile exploration. Whether tackling rough backroads, remote gravel routes, or mixed-surface adventures, the Scale Gravel delivers the performance and capability needed to venture beyond where pavement ends.
Built on the Scale Carbon HMF frame and fork featuring advanced monocoque construction, this platform uses only one mold for the front triangle, resulting in just three separate pieces molded together. This revolutionary approach increases efficiency by reducing junction points while maintaining superior stiffness and decreasing weight—the hallmarks of SCOTT's hardtail race bike heritage. The monocoque design enables the frame to handle forces as a unified system, delivering exceptional power transfer and durability across demanding terrain.
Thoughtful engineering details enhance the Scale Gravel 10's versatility and serviceability. A small service door accessible through the downtube cover provides easy interior frame access for cable routing maintenance without removing the bottom bracket. The advanced hollow dropout construction allows the axle head to clamp against the inner surface and sit flush with the exterior, saving 7.5g while enabling a narrower rear triangle design that reduces an additional 20g for optimized weight distribution.
Perfect for riders seeking lightweight gravel performance with adventure-ready features, the Scale Gravel 10 pairs its advanced carbon platform with SRAM S1000 AXS Transmission wireless electronic shifting for precise, reliable gear changes and Syncros X-28TR rims for dependable performance. This is gravel exploration with the attitude and engineering excellence that defines SCOTT.
Key Features
- Frame - Scale Carbon HMF Monocoque Frame and Fork
- Drivetrain - SRAM S1000 AXS Transmission 12-Speed Wireless
- Wheelset - Syncros X-28TR Rims
| Specification | Detail |
|---|---|
| Frame | Scale Carbon HMF, Adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92, UDH Interface, 12x148mm with 55mm Chainline |
| Fork | Scale Rigid HMF, Postmount Disc Standard, Tapered Carbon steerer |
| Rear Derailleur | SRAM S1000 Eagle AXS Transmission, 12 Speed, Wireless Electronic Shift System |
| Shifters | SRAM AXS Pod Controller |
| Crankset | SRAM Eagle 70 Transmission, DUB, 55mm Chainline, 34T |
| Chainguide | SCOTT custom |
| Bottom Bracket | SRAM DUB PF 92 MTB Wide, shell 41x92mm |
| Chain | SRAM CN Eagle 70 Transmission |
| Cassette | SRAM Eagle XS 1270 V2 Transmission, 10-52T |
| Brakes | SRAM DB6 4-Piston Disc |
| Rotor | SRAM Centerline CL Rotors, 180mm Front / 160mm Rear |
| Handlebar | Syncros Fraser 2.0 XC Alloy 6061 D.B., Flat Bar, 8°, 740mm, Syncros Performance XC lock-on grips |
| Stem | Syncros XC 2.0, Syncros Cable Integration System, -12° rise, 6061 Alloy, 31.8mm, 1 1/8" |
| Seatpost | Syncros Duncan 2.0, 10mm offset, 31.6x400mm |
| Saddle | Syncros Belcarra V2.0 Cut Out, CRMO rails |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System, ±0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Front Hub | Formula CL-811, 15x110mm |
| Rear Hub | Formula CL-3248, 12x148mm |
| Spokes | Stainless Black 15G, 1.8mm |
| Rims | Syncros X-28, 28H, Tubeless ready |
| Front Tire | Maxxis Aspen, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO |
| Rear Tire | Maxxis Aspen, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO |
| Extras | SRAM AXS Powerpack |
| Accessories | Spirgrips+ Inner Bar Ends |
| Approx. Weight | 10.5kg / 23.15lbs (Tubeless setup) |
| Max. System Weight | 120kg (includes bike, rider, equipment, and additional luggage) |
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Head Tube Angle | 67.9° | 67.9° | 67.9° | 67.9° |
| Head Tube Length (mm) | 90.0 mm | 95.0 mm | 110.0 mm | 120.0 mm |
| Top Tube Horizontal (mm) | 575.0 mm | 600.2 mm | 626.0 mm | 656.5 mm |
| Standover Height (mm) | 752.0 mm | 781.0 mm | 800.0 mm | 835.1 mm |
| BB Offset (mm) | -62.0 mm | -62.0 mm | -62.0 mm | -62.0 mm |
| BB Height (mm) | 313.0 mm | 313.0 mm | 313.0 mm | 313.0 mm |
| Wheelbase (mm) | 1105.4 mm | 1131.1 mm | 1158.0 mm | 1189.4 mm |
| BB Center to Top of Seat Tube (mm) | 390.0 mm | 440.0 mm | 480.0 mm | 530.0 mm |
| Seat Angle | 75.4° | 75.4° | 75.3° | 75.3° |
| Chainstay (mm) | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm |
| Reach (mm) | 418.5 mm | 442.3 mm | 463.6 mm | 491.2 mm |
| Stack (mm) | 600.3 mm | 604.9 mm | 618.9 mm | 628.1 mm |
| Stem Length (mm) | 50.0 mm | 60.0 mm | 70.0 mm | 80.0 mm |
| Trail (mm) | 105.0 mm | 105.0 mm | 105.0 mm | 105.0 mm |
| Fork Length (mm) | 506.0 mm | 506.0 mm | 506.0 mm | 506.0 mm |
| Maximum Seatpost Insertion (mm) | 160.0 mm | 210.0 mm | 250.0 mm | 300.0 mm |
| Crank Length (mm) | 170.0 mm | 170.0 mm | 175.0 mm | 175.0 mm |
