BMC Roadmachine 01 AMP THREE
Product Details
The BMC Roadmachine 01 AMP THREE brings the endurance-focused Roadmachine lineage into the electric era. The premium carbon frame is built around BMC's Tuned Compliance Concept Endurance technology, absorbing road vibration and impacts while staying stiff enough for efficient power transfer, a fast, forgiving ride built for long days and hard efforts.
The TQ-HPR50 Class 3 drive unit integrates cleanly into the frame for a natural pedal-assist feel, backed by a 360Wh battery with enough range to push well beyond normal limits. A custom BMC backlight connects directly to the battery, and the ICS2 integration system keeps cables internal while adding stiffness and mounting points for accessories.
Shimano 105 Di2 electronic shifting handles the drivetrain, paired with tubeless-ready XRD-522 wheels (25mm internal width) and generous tire clearance for varied road surfaces.
Key Features
- Frame: Roadmachine 01 AMP Premium Carbon with Tuned Compliance Concept Endurance
- Motor: TQ-HPR50 Drive Unit Class 3 with TQ Battery 360Wh (UL Certified)
- Drivetrain: Shimano 105 Di2 Electronic Shifting
- Wheelset: XRD-522 Tubeless Ready (25mm Internal Width)
| Category | Specification |
|---|---|
| Frame | Roadmachine 01 AMP Premium Carbon with Tuned Compliance Concept Endurance | Integrated Battery | Internal Cable Routing | ICS Technology Stealth Cable Routing | Fender Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle |
| Fork | Roadmachine 01 AMP | 01 Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle |
| Drive Unit | TQ-HPR50 Drive Unit |
| Battery Pack | TQ Battery | 360 Wh | Certified by UL LLC | NYC Lithium-Ion Battery Safety Guidelines |
| Display | TQ Display | 2" O-LED | Bluetooth / ANT+ |
| Charger | TQ-HPR50 4A Charger |
| Stem | BMC ICS2 | Integrated Cockpit System Technology |
| Handlebar | BMC RAB 02 | Ergo Top Shape | Compact Bend |
| Seatpost | Roadmachine 01 AMP Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible |
| Saddle | Fizik Argo Tempo R5 | 150mm |
| Crankset | Rotor eVegast |
| Chainrings | 50-34T |
| Cassette | SHIMANO (CS-HG710) | 11-36T |
| Chain | SHIMANO CN-M8100 |
| Front Derailleur | SHIMANO 105 Di2 (FD-R7150) |
| Rear Derailleur | SHIMANO 105 Di2 (RD-R7150) |
| Shifters | SHIMANO 105 Di2 (ST-R7170) |
| Gears | 2 x 12 |
| Brakes | SHIMANO 105 (BR-R7170) |
| Rotors | SHIMANO SM-RT64 | Centerlock | 180/180mm |
| Rims | XRD-522 | Tubeless Ready | 25 mm |
| Hubs | XRD-522 (F/R) |
| Tires | Pirelli Cinturato Velo TLR | 32mm |
| Tubeless Info | Tubeless Ready Rims | Tubetype Tires |
| Accessories | Integrated Rear Light |
| Tire Clearance | Up to 38mm measured (frameset clearance) but limited to 34mm measured by front derailleur |
| Weight (w/o pedals) | 13.1 Kg |
| System Weight Limit | 120 Kg |
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height (cm) | <162 | 162–174 | 172–180 | 178–186 | 184–192 | >190 |
| Reach (mm) | 370 | 379 | 383 | 388 | 393 | 398 |
| Stack (mm) | 525 | 550 | 570 | 595 | 620 | 645 |
| Bar Drop (mm) | 125 | 125 | 125 | 125 | 125 | 125 |
| Bar Reach (mm) | 70 | 70 | 70 | 70 | 70 | 70 |
| Bar Width (mm) | 400 | 420 | 420 | 420 | 420 | 440 |
| BB Drop (mm) | 75 | 75 | 75 | 75 | 75 | 75 |
| Crank Length (mm) | 170 | 170 | 170 | 170 | 170 | 170 |
| Fork Length (mm) | 380 | 380 | 380 | 380 | 380 | 380 |
| Fork Rake (mm) | 50 | 50 | 45 | 45 | 45 | 45 |
| Front Center (mm) | 579 | 596 | 594 | 607 | 620 | 633 |
| Head Tube (mm) | 112 | 138 | 154 | 181 | 207 | 233 |
| Head Tube Angle | 71.4° | 71.4° | 72.2° | 72.2° | 72.2° | 72.2° |
| Rear Center (mm) | 420 | 420 | 420 | 420 | 420 | 420 |
| Seat Angle | 74.2° | 74.2° | 74.2° | 74.2° | 74.2° | 74.2° |
| Seat Tube (mm) | 420 | 460 | 500 | 525 | 545 | 575 |
| Seatpost Length (mm) | 330 | 380 | 380 | 380 | 380 | 430 |
| Seatpost Offset (mm) | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height (mm) | 728 | 755 | 786 | 810 | 829 | 850 |
| Stem Angle | -12.5° | -12.5° | -12.5° | -12.5° | -12.5° | -12.5° |
| Stem Length (mm) | 90 | 100 | 100 | 110 | 110 | 120 |
| Top Tube (mm) | 519 | 535 | 544 | 556 | 568 | 581 |
| Trail (mm) | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase (mm) | 987 | 1005 | 1002 | 1015 | 1028 | 1041 |
