Product Description
The SCOTT Ransom 400 was constructed to turn childhood dreams of flight and speed into reality. With 24” inch wheels, a kid-tuned long travel fork (140mm) and shock (130mm) in combination with a flip chip, the Ransom can grow, or shrink, to run 26” or 24” inch wheels.
One long travel enduro bike to rule them all! With 140mm smooth suspension travel front and rear in unison, you can point the SCOTT Ransom 400 down the mountain and let it eat up whatever lies below. With the strongest carbon construction to date and kid-specific geometry, once aboard the Ransom 400 you can reap the rewards of partaking in what was previously coded as risky behavior.
SCOTT is about flexibility and versatility which is why the Ransom 400 frame is able to fit both 24” and 26” wheels. Flip a chip on the shock mount when moving between wheel sizes and you’re ready to rumble down the trail. We love the simplicity of this feature because it means that you don’t have to change forks which saves you time and money.
When you’re on the hunt for the best dirt on the mountain there is always some climbing involved. On the uphills you’ll come to appreciate the Ransom 400’s low weight. The bike comes in at a shocking 13.60kg, a benchmark for the industry. However, do not fear, the lack of weight doesn't have a negative impact on the bike's sturdiness. SCOTT utilized their clever carbon layups for strategic reinforcement in key areas. Enduro frames need to be ready for the worst and the SCOTT Ransom 400 is prepared to take a beating.
REVIEWS
Geometry
24" | 26" | ||
HIGH BB Setting | LOW BB Setting | ||
A | head tube angle | 65.7 ° | 65.0 ° |
B | head tube length | 90.0 mm | 90.0 mm |
C | top tube horizontal | 497.7 mm | 499.1 mm |
D | standover height | 597.9 mm | 621.5 mm |
E | BB offset | -13.0 mm | -21.0 mm |
F | BB height | 305.0 mm | 325.0 mm |
G | wheel base | 1,078.3 mm | 1,080.2 mm |
H | BB center to toptube center | ||
I | BB center to top of seattube | 320.0 mm | 320.0 mm |
J | seat angle | 76.7 ° | 76.0 ° |
K | chainstay | 422.6 mm | 425.0 mm |
L | reach | 366.8 mm | 360.0 mm |
M | stack | 553.6 mm | 558.1 mm |
N | stem length | 40.0 mm | 50.0 mm |
0 | trail | 98.6 mm | 116.1 mm |
Specifications
-
Frame
Ransom 24"/26" Alloy 6061 Custom butted tubing
Tapered headtube / BB73
Internal cable routing
UDH 148x12mm -
Fork
X-Fusion Slant RC 26 / 140mm / tapered
Kids Bike Tune -
Rear Shock
X-Fusion 02Pro R Trunnion
Rebound Adjuster / Kids Bike Tune
Travel 130mm / 165x45mm -
Rear Derailleur
Shimano Deore RD-M5100 11-Speed -
Shifters
Shimano Deore SL-M5100-R -
Crankset
Prowheel CHARM-32T 2PC
Boost / 127mm -
BB-Set
Prowheel BB73 -
Chain
KMC X11 -
Cassette
Shimano CS-M5100-11 / 11-51 -
Brake Levers
Shimano BL-MT501 -
Brakes
Shimano BR-MT500 -
Rotor
Shimano Deore SM-RT56 / IS / F: 180 R: 160 -
Handlebar
Syncros T-Bar / Alloy 6061
T shape Flat / 9° / 600mm
Syncros Youth 115 -
H'stem
Syncros 6061 Alloy
Oversized 31.8mm / 1 1/8" / 7° angle -
Seatpost
Syncros Dropper Ducan Remote
31.6mm / 80mm / Kid centric custom tune -
Seat
Syncros Future Pro -
Headset
Syncros OE Press Fit / Reduce 1.5"-1 1/8"
OD 50/62mm / ID 44/56mm -
Hub (Front)
Formula DC-71 IS / 15x110mm -
Hub (Rear)
Formula DC-3248 IS / Boost 12x148mm -
Spokes
Stainless Black 15g / 1.8mm -
Rims
Syncros DP30 / 32H / 30mm -
Front Tire
Kenda Hellkat K1201 / 60TPI / folding / 24x2.4 -
Rear Tire
Kenda Hellkat K1201 / 60TPI / folding / 24x2.4 -
Pedals
Wellgo J345 / w/Reflector -
Approx weights in KG
13.60 -
Approx weights in LBS
29.98 -
Max. System Weight
80 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
