BMC Roadmachine 01 One
Product Details
The BMC Roadmachine 01 One is designed for riders who demand the perfect balance of endurance and speed without being confined to a single surface. Built for those who want to go the distance, this third-generation Roadmachine represents BMC's relentless pursuit of the endurance formula—combining serious advancements in stiffness and layup with the most considerate all-terrain capabilities.
Crafted with BMC's Premium Carbon utilizing expert composite layup knowledge from the Impec Lab, the Roadmachine 01 achieves a sub-1kg frameset (size 54) with data-proven compliance and torsional stiffness. Optimized for 32–35mm tires with clearance up to 40mm, the geometry features a short rear center, dropped bottom bracket, revised head tube angle, and increased stack for a responsive yet comfortable ride.
Integration is taken to the next level with the ICS Carbon Evo cockpit, D-shape seatpost with integrated rear light, downtube storage with water-repellent pouch, and full fender compatibility. Equipped with Shimano Dura-Ace electronic shifting, a 4iiii dual-sided power meter, and a CE 40 SL carbon wheelset, the Roadmachine 01 One redefines what an endurance road bike can be.
Key Features
- Frame - BMC Roadmachine 01 Gen 3 Premium Carbon with Tuned Compliance Concept Endurance
- Drivetrain - Shimano Dura-Ace with 4iiii Dual-Sided Power Meter
- Wheelset - BMC CE 40 SL Carbon Tubeless Ready with 40mm Profile
| Specification | Detail |
|---|---|
| Frame | Roadmachine 01 Gen 3 | 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology Stealth Cable Routing | Integrated Downtube Storage | Full Mount - UDH | 12 x 142mm Thru-Axle |
| Fork | Roadmachine 01 Gen 3 | 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology stealth cable routing | Flat Mount Disc | 12 x 100mm Thru-Axle | 50mm offset (Size 47-51) 45mm offset (Size 54-61) |
| Handlebar | ICS Carbon Evo | One Piece Full Carbon Cockpit | 127mm drop, 70mm reach, 8° flare |
| Grips | BMC Tacky 3mm |
| Seatpost | Roadmachine 01 Premium Carbon D-Shaped Seatpost | 0mm Offset Size 47-51 and 15mm Offset Size 54-61 | D-Fender Compatible |
| Saddle | Selle Italia Novus Boost Evo Superflow | TI316 Rail | 145mm |
| Crankset | SHIMANO Dura Ace (FC-R9200) |
| Chainrings | 50-34T |
| Power Meter | 4iiii Precision Gen3+ Power Meter (Dual Side) |
| Cassette | SHIMANO Dura Ace (CS-R9200) |
| Cassette Size | 11-34T |
| Chain | SHIMANO CN-M9100 |
| Front Derailleur | SHIMANO Dura Ace Di2 (FD-R9250) |
| Rear Derailleur | SHIMANO Dura Ace Di2 (RD-R9250) |
| Shifters | SHIMANO Dura Ace Di2 (ST-R9270) |
| Gears | 2 x 12 |
| Bottom Bracket | SHIMANO Dura Ace Press-Fit Bottom Bracket (SM-BB92-41B) |
| Brakes | SHIMANO Dura Ace (BR-R9270) |
| Rotors | SHIMANO Dura Ace (RT-CL900) |
| Rotor Size (F/R) | 160 / 160mm |
| Rims | CE 40 SL Carbon | Tubeless Ready | 40mm |
| Hubs (F/R) | TXC-812 & TXC-240A Center Lock |
| Tires | Vittoria Corsa N.EXT | Tubeless | 32mm |
| Tubeless Info | Tubeless Rim | Tubeless Tires |
| In the Box | Integrated Rear Light 25 | Roadmachine Bottle Cages | Storage Pouch | Computer mount for Garmin, Wahoo and GoPro mount |
| Tire Clearance | Up to 40mm measured (frameset clearance), limited to 36mm measured by front derailleur |
| Weight (No Pedals) | 7.7kg | Size 54 as pictured with all accessories |
| ASTM Classification | Level 2 |
| System Weight Limit | 110kg |
| Measurement | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height (cm) | <160 | 158–174 | 172–180 | 178–186 | 184–192 | >190 |
| Reach (mm) | 370 | 379 | 383 | 388 | 393 | 398 |
| Stack (mm) | 525 | 550 | 570 | 595 | 620 | 645 |
| Bar Drop (mm) | 127 | 127 | 127 | 127 | 127 | 127 |
| Bar Reach (mm) | 68 | 68 | 68 | 68 | 68 | 68 |
| Bar Width (mm) | 400 / 436 | 400 / 436 | 400 / 436 | 400 / 436 | 400 / 436 | 400 / 436 |
| BB Drop (mm) | 75 | 75 | 75 | 75 | 75 | 75 |
| Crank Length (mm) | 165 | 167.5 | 170 | 170 | 172.5 | 172.5 |
| Fork Length (mm) | 379 | 379 | 379 | 379 | 379 | 379 |
| Fork Rake (mm) | 50 | 50 | 45 | 45 | 45 | 45 |
| Front Center (mm) | 579 | 596 | 594 | 607 | 620 | 633 |
| Head Tube Length (mm) | 112 | 138 | 154 | 181 | 207 | 233 |
| Head Tube Angle (°) | 71.4° | 71.4° | 72.2° | 72.2° | 72.2° | 72.2° |
| Rear Center (mm) | 415 | 415 | 415 | 415 | 415 | 415 |
| Seat Tube Angle (°) | 74.2° | 74.2° | 74.2° | 74.2° | 74.2° | 74.2° |
| Seat Tube Length (mm) | 414 | 461 | 488 | 508 | 529 | 550 |
| Seatpost Length (mm) | 310 | 360 | 360 | 360 | 400 | 400 |
| Seatpost Offset (mm) | 0 | 0 | 15 | 15 | 15 | 15 |
| Standover Height (mm) | 726 | 762 | 786 | 807 | 828 | 849 |
| Stem Angle (°) | -12° | -12° | -12° | -12° | -12° | -12° |
| Stem Length (mm) | 70 | 80 | 90 | 100 | 100 | 110 |
| Top Tube Length (mm) | 520 | 537 | 546 | 559 | 571 | 581 |
| Trail (mm) | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase (mm) | 982 | 1000 | 997 | 1010 | 1023 | 1036 |
