Cervélo Caledonia-5 Rival AXS
Contender Signature Service
A complimentary $300 value covering professional assembly, tuning, inspection, and careful re-packaging by our technicians.
Request Info
Cervélo Caledonia-5 Rival AXS
Product Details
The Cervélo Caledonia-5 is built for Big, Stupid Rides, the ultra-distance, ultra-fast efforts that define the outer limits of endurance cycling. Since its introduction, athletes around the world have been exploring just how big and how stupid those rides can be, and the Caledonia-5 is engineered to handle it all. This is a race bike designed for long-distance, high-speed racing where fit and handling are geared toward comfort without sacrificing the legendary Cervélo race bike feeling that demands performance when it counts.
Every refinement on the new Caledonia-5 addresses what matters to riders pushing their bodies and equipment to the absolute limit. The most significant addition is integrated in-frame storage, designed discreetly for a small multi-tool, spare tube, and CO2 canister. Out of sight, out of mind until you need it most. The dropped seatstays, inspired by Cervélo's gravel platform, make the rear triangle more acute and vertically flexible, absorbing chatter on imperfect tarmac while a bit more downtube stiffness maintains the pro-level responsiveness Caledonia is known for. This balance ensures you stay fresh over the brutal hours of ultra-distance racing.
Completely internal cable routing and carefully optimized aero tube shapes provide the free speed every Cervélo delivers, helping you battle the wind when running on fumes. Split bearing caps allow fit adjustments without bleeding the brakes, simplifying setup for the inevitable fine-tuning long rides demand. With 36mm tire clearance and fender mounts, you're equipped for any surface and any weather.
SRAM Rival AXS E1 electronic drivetrain with integrated power meter delivers precise, wireless shifting across changing terrain and pace, while Reserve 42|49TA carbon wheels, proven across Paris-Roubaix and Grand Tours alike, provide all-day capability with aerodynamic sensibilities.
Key Features
- Frame - Cervélo All-Carbon
- Drivetrain - SRAM Rival AXS E1 2x with integrated power meter
- Wheelset - Reserve 42|49TA carbon, DT Swiss 370 hubs
| Specification | Detail |
|---|---|
| Sizes | 48cm, 51cm, 54cm, 56cm, 58cm, 61cm |
| Weight | 7.42 kgs |
| Fork | Cervélo All-Carbon, Tapered Caledonia-5 Fork |
| 1-piece Handlebar/Stem | Cervélo HB18 Carbon |
| Handlebar Sizing | Size 48 - 36cm Size 51 - 38cm Size 54 - 40cm Size 56 - 40cm Size 58 - 40cm Size 61 - 40cm |
| Stem Sizing | Size 48 - 80mm Size 51 - 90mm Size 54 - 100mm Size 56 - 100mm Size 58 - 110mm Size 61 - 110mm |
| Seatpost | Cervélo SP33 Carbon |
| Seatpost Sizing | Size 48 - 0mm Size 51 - 0mm Size 54 - 0mm Size 56 - 0mm Size 58 - 15mm Size 61 - 15mm |
| Saddle | Prologo Nago R4 PAS Tirox Lightweight |
| Bottom Bracket | SRAM DUB, BBright |
| Headset | FSA IS2 1-1/4, 45° x 45° / 1-1/2, 36° x 45° |
| Front Thru Axle | Cervélo Aero Thru Axle Front, M12x1.5mm, 127mm length |
| Rear Thru Axle | Cervélo Aero Thru Axle Rear, M12x1.75mm, 170.5mm length |
| Front Wheel | Reserve 42TA, DT Swiss 370, 12x100mm, 24H, centerlock, tubeless compatible |
| Rear Wheel | Reserve 49TA, DT Swiss 370, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible |
| Tires | Vittoria Corsa N.EXT TLR G2.0 700x32c |
| Shifter/Brake Levers | SRAM Rival AXS E1 |
| Crankset | SRAM Rival AXS E1, 48/35T, DUB, with power meter |
| Power Meter | |
| Crank Sizing | Size 48 - 160mm Size 51 - 165mm Size 54 - 170mm Size 56 - 170mm Size 58 - 172.5mm Size 61 - 172.5mm |
| Chain | SRAM Rival E1 |
| Cassette | SRAM Rival D1, 10-36T, 12-Speed |
| Front Derailleur | SRAM Rival AXS E1 |
| Rear Derailleur | SRAM Rival AXS E1 |
| Brake Rotors | SRAM Paceline Centerlock |
| Accessories | - Cervélo Removeable Fender Mounts - Cervélo Rear Accessory Mount - Cervélo In-Frame Storage Rolls - Inner Tube Storage - Cervélo In-Frame Storage Rolls - Flat Kit Storage - Arundel Mandible Water Bottle Cage, Matte UD Carbon finish (2 qty) - Cervélo Front Computer/Accessory Mount 266 |
| Size | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Reach | mm | 360 | 369 | 378 | 387 | 396 | 405 |
| Stack | mm | 505 | 530 | 555 | 580 | 605 | 630 |
| Head Tube Angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| Front Center | mm | 580.5 | 582.7 | 592.5 | 609.5 | 627 | 644.1 |
| Bottom Bracket Drop | mm | 76.5 | 76.5 | 74 | 74 | 71.5 | 71.5 |
| Head Tube Length | mm | 89.5 | 110.3 | 136.3 | 162.6 | 191.5 | 217.8 |
| Top Tube Length | mm | 502 | 522 | 543 | 565 | 581 | 598 |
| Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Standover Height | mm | 701 | 743 | 775 | 798 | 824 | 847 |
| Trail | mm | 57.8 | 57.8 | 57.8 | 57.8 | 57.8 | 57.8 |
| Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Fork Offset | mm | 60 | 54 | 51 | 51 | 51 | 51 |
| Wheelbase | mm | 983.3 | 985.6 | 996.3 | 1013.4 | 1031.8 | 1048.9 |
| Chainstay Length | mm | 415 | 415 | 415 | 415 | 415 | 415 |
