ENVE Melee Frameset
Product Details
The ENVE Melee represents a nuanced approach to the modern road race bike, overlaying the customizable aspect of ENVE's Custom Road with a standard size range to provide a balance of personalization and performance. Race-bred and built for speed, this frameset features refined tube shaping and reduced weight, achieving a compromise that enhances both handling and comfort without sacrificing quality, designed for riders whose minds are prepped, bodies ready, and equipment on point.
Built on ENVE's Material Optimized Design (M.O.D.) carbon platform for both frame and fork, the Melee benefits from decades of carbon fiber refinement and expertise. The carbon fibers are meticulously layered and oriented to achieve zone-specific performance requirements, creating the perfect hybrid of stiffness and compliance. Continuous fibers run throughout the frame and fork with tapered laminates and excess material removed to save weight, resulting in a responsive ride that maintains essential comfort for long-distance racing.
Developed in CFD and the wind tunnel, the Melee features refined tube shapes tuned to complement ENVE's SES rim shapes, delivering Real-World Fast aerodynamic performance balanced for aero efficiency and weight savings.
Perfect for competitive riders seeking optimized fit and tuned geometry, the Melee is offered in seven frame sizes with five fork rakes, ensuring responsive, confidence-inspiring handling regardless of rider size. The threaded T47 inboard-bearing bottom bracket delivers smooth, silent, creak-free operation. Geometry and handling characteristics are optimized for 27-32mm tires with clearance up to 35mm, while drivetrain compatibility spans most brands and configurations including mechanical, electronic wired, electronic wireless, 1x, and 2x setups.
The Melee frameset provides a blank canvas for building a dream bike.
Key Features
- Frame – ENVE M.O.D Carbon with Advanced Fiber Layering and Construction
- Aerodynamics – Real-World Fast Tube Shaping Complementing SES Rim Profiles
- Clearance – 35mm Maximum (Optimized for 27-32mm) with Threaded T47 Bottom Bracket
| Specification | Detail |
|---|---|
| Frame Material | ENVE M.O.D Carbon |
| Fork Material | ENVE M.O.D Carbon |
| Target Application | Road Race / Performance |
| Sizes (cm) | 47, 50, 52, 54, 56, 58, 60 |
| Fork Rake | 55, 51, 47, 43, 39 |
| Frame Size / Fork Rake | 47cm/55, 50cm/51, 52cm/47, 54cm/47, 56cm/43, 58cm/43, 60cm/39 |
| Frame Weight | 850g ±2% (Size 56, Painted, No Hardware) |
| Headset | ENVE Integrated IS52/IS52 Internal Drop-In |
| Headset Bearing | 1.5″ IS52 Upper and Lower |
| Seatpost Diameter | ENVE Aero |
| Bottom Bracket Type | T47 Inboard Bearing |
| Brake Mount | Flat Mount |
| Front Axle | 12×100 (Total Length: 122, TP: 1.5, TL: 15) |
| Rear Axle | 12×142 (Total Length: 168, TP: 1.5, TL: 14) |
| Minimum Tire Size | 25c |
| Optimal Tire Size | 27c–32c |
| Maximum Listed Tire Clearance | 35c |
| Frame Routing | Internal |
| Component | SRAM Rival AXS | SRAM Force AXS D2 | SRAM RED AXS E1 | Shimano 105 Di2 12spd | Shimano Ultegra Di2 12spd | Shimano Dura-Ace Di2 12spd |
|---|---|---|---|---|---|---|
| Levers/Calipers | SRAM RIVAL eTap AXS HRD Lever/Caliper | SRAM Force AXS HRD eTap D2 Lever/Caliper | SRAM RED AXS HRD Lever/Caliper | Shimano ST-R7170 105 Brake/Shift Lever + CALIPER | Shimano ST-R8170 Ultegra Brake/Shift Lever + CALIPER | Shimano ST-R9270 Dura-Ace Brake/Shift Lever + CALIPER |
| Crankset | SRAM Rival DUB Crankset | SRAM Force DUB Crankset | SRAM RED AXS DUB Crankset | Shimano 105 FC-R7100 Crankset | Shimano Ultegra FC-R8100 Crankset | Shimano Dura-Ace FC-R9200 Crankset |
| Front Derailluer | SRAM Rival AXS Front Derailleur | SRAM Force AXS D2 Front Derailleur | SRAM RED AXS E1 Front Derailleur | Shimano 105 Di2 FD-R7150 Front Derailleur | Shimano Ultegra Di2 FD-R8150 Front Derailleur | Shimano Dura-Ace Di2 FD-R9250 Front Derailleur |
| Rear Derailluer | SRAM Rival AXS Rear Derailleur | SRAM Force AXS D2 Rear Derailleur | SRAM RED AXS E1 Rear Derailleur | Shimano 105 Di2 RD-R7150 Rear Derailleur | Shimano Ultegra Di2 RD-R8150 Rear Derailleur | Shimano Dura-Ace Di2 RD-R9250 Rear Derailleur |
| Chain | SRAM Rival Chain | SRAM Force Chain | SRAM Red E1 Chain | CN-M7100 Chain | CN-M8100 Chain | CN-M9100 Chain |
| Cassette | SRAM Rival AXS Cassette | SRAM Force AXS Cassette | SRAM RED AXS E1 Cassette | Shimano 105 CS-R7101-12 Cassette | Shimano Ultegra CS-R8100-12 Cassette | Shimano Dura-Ace CS-R9200-12 Cassette |
| Rotors | SRAM Centerline Rotor | SRAM Paceline Rotor | SRAM Paceline X Rotor | Shimano SM-RT70 Rotor | Shimano RT-CL800 Rotor | Shimano RT-CL900 Rotor |
| Battery/Extras | Batt/Charger | Batt/Charger | Batt/Charger | Battery/Wires/Charger | Battery/Wires/Charger | Battery/Wires/Charger |
| Measurement | 47 | 50 | 52 | 54 | 56 | 58 | 60 |
|---|---|---|---|---|---|---|---|
| Reach (mm) | 370 | 376 | 381 | 386 | 394 | 400 | 408 |
| Stack (mm) | 509 | 525 | 539 | 552 | 571 | 589 | 609 |
| Top Tube (mm) | 506 | 522 | 536 | 547 | 563 | 578 | 598 |
| Fork Rake (mm) | 55 | 51 | 47 | 47 | 43 | 43 | 39 |
| Seat Tube Length (C–T) (mm) | 417 | 434 | 452 | 466 | 490 | 508 | 531 |
| Max Saddle Rail Height (w/ 350 mm Post) | 692 | 709 | 727 | 741 | 765 | 783 | 806 |
| Max Saddle Height (w/ ENVE SLR Saddle) | 728 | 745 | 763 | 777 | 801 | 819 | 842 |
| Seat Tube Angle | 75.1° | 74.5° | 74° | 73.8° | 73.5° | 73.2° | 72.7° |
| Head Tube Angle | 71.1° | 71.5° | 72.2° | 72.4° | 73.3° | 73.3° | 73.6° |
| Head Tube Length (mm) | 105 | 120 | 130 | 145 | 160 | 180 | 200 |
| BB Drop (mm) | 75 | 75 | 75 | 73 | 73 | 71 | 71 |
| Chainstay Length (mm) | 410 | 410 | 410 | 410 | 410 | 412 | 412 |
| Wheelbase (mm) | 980 | 983 | 983 | 991 | 992 | 1006 | 1013 |
| Front Center (mm) | 582 | 585 | 584 | 592 | 593 | 605 | 611 |
| Standover (mm) | 693 | 710 | 728 | 744 | 768 | 787 | 809 |
| BB Height (29 mm Tire) (mm) | 268 | 268 | 268 | 270 | 270 | 272 | 272 |
| Trail (27 mm Tire) (mm) | 58.1 | 59.3 | 59.1 | 57.9 | 56.8 | 56.5 | 58.1 |
| Trail (29 mm Tire) (mm) | 58.8 | 59.8 | 59.7 | 58.4 | 57.3 | 57 | 58.7 |
| Trail (31 mm Tire) (mm) | 59.4 | 60.4 | 60.2 | 59 | 57.8 | 57.5 | 59.2 |
| Trail (33 mm Tire) (mm) | 60.2 | 61.2 | 61 | 59.7 | 58.5 | 58.2 | 59.9 |
| Trail (35 mm Tire) (mm) | 60.9 | 62 | 61.7 | 60.4 | 59.2 | 58.9 | 60.5 |
