Mondraker Arid Carbon S AXS
Product Details
The Mondraker Arid Carbon S AXS combines a Stealth Air Carbon frame with SRAM S1000 Eagle AXS T-Type 12-speed shifting. Its appeal extends beyond the drivetrain. The chassis is designed to feel responsive under power while taking the edge off rough surfaces, and its integrated storage and mounting options support the longer, less predictable rides that make gravel so rewarding.
The frame's Stealth Air Carbon layup is tailored for a firm pedaling platform without an unnecessarily harsh ride. Stiffness around the head tube and bottom bracket works alongside a more compliant rear triangle, helping the bike maintain its rhythm on broken surfaces. Forward Geometry guides the handling, while a T47 bottom bracket, UDH interface and 12x142mm rear axle define the build standards. HHG internal routing keeps cables neatly integrated into the frame.
A rigid Stealth Air Carbon fork complements the frame, with a tapered steerer, HHG routing and an integrated flat-mount brake interface. Clearance for tires up to 50mm wide gives riders room to favor faster rolling or greater rough-surface comfort. The rigid layout keeps the connection to the ground direct, with the carbon construction and tire setup shaping the ride feel.
The SRAM S1000 Eagle AXS T-Type drivetrain supplies 12-speed shifting. Mavic Allroad Disc wheels use hookless rims with a 25mm internal width and 28 spokes. The Infinity rear hub has ID360 ratchet engagement, Centerlock rotor mounting and an HG freehub. Together, the wheels and drivetrain complement a chassis designed to handle a broad mix of unpaved routes.
Longer days benefit from the Carry-On storage system, which places three organized pouches inside the downtube behind a watertight, dustproof cover. Tools and small essentials can stay with the bike instead of filling pockets. Mounts on the frame and fork support flexible bottle and accessory arrangements, including positions beneath the downtube and on the top tube. The five-size range includes S, M, M/L, L and XL, with an intermediate option for riders between medium and large.
Key Features
- Frame - Arid Stealth Air Carbon
-
Drivetrain - SRAM S1000 Eagle AXS T-Type, 12-speed
- Wheelset - Mavic Allroad Disc with Infinity hubs
| Specification | Detail |
|---|---|
| Frame | Arid Stealth Air Carbon, in-tube storage, T47 bottom bracket, tapered head tube, HHG internal cable routing, 12x142mm rear axle, UDH, 1X drivetrain design, Flatmount brake compatible. |
| Sizes | S: 410mm / M: 450mm / ML: 480mm / L: 510mm / XL: 540mm |
| Fork | Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork |
| Headset | Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing. |
| Stem | Onoff Semi-Integrated, 31.8mm barbore, rise: -7°, length S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm |
| Handlebar | Onoff S3 GR 16º bar flare. Width sizes S size: 400mm M size: 420mm ML size: 420mm L size: 440mm XL size: 460mm |
| Grips | Onoff HEX Bartape |
| Seatpost | Onoff S9 Carbon 15-R, diameter 27.2mm, length S size: 400mm, M size: 400mm, ML size 400mm, L size: 450m, XL size: 450mm |
| Saddle | Fizik Vento Argo X5 140mm |
| Front Brake | Sram Apex AXS, 2 piece caliper, Paceline 160mm Centerlock rotor, steel-backed organic pad |
| Rear Brake | Sram Apex AXS, 2 piece caliper, Paceline 160mm Centerlock rotor, steel-backed organic pad |
| Brake Lever | Sram Apex, contact point adjustment, tooled reach adjust, aluminum levers |
| Rims | Mavic Allroad Disc, 25mm internal width, hookless, 28 spokers |
| Spokes | Mavic Steel J Bent spokes |
| Front Hub | Mavic, 12x100mm, Centerlock |
| Rear Hub | Mavic infinity hub, 12x142mm, XD ID360 Ratchet system, Centerlock, HG Freehub |
| Front Tire | Maxxis Reaver 700x45, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead |
| Rear Tire | Maxxis Reaver 700x45, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead |
| Crankset | Sram Apex 1 Wide S size: 165mm M size: 165mm ML size: 170mm L size: 172,5mm XL size: 172,5mm, CL 47,5 |
| Rings | Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide, |
| Bottom Bracket | Sram DUB T47 BSA, sealed bearings, 85,5mm |
| Chain | Sram GX Eagle T-Type, 12s Flattop, Powerlock |
| Rear Derrailleur | Sram S1000 Eagle AXS T-Type, 12s |
| Shift Levers | Sram Apex AXS D1 12s, |
| Cassette | Sram XS-1270, 10-52T, T-Type, 12s |
| Weight | 21.8 lbs |
| Frame Size | S | M | M/L | L | XL |
|---|---|---|---|---|---|
| Seat Tube Length (mm) | 410 | 450 | 480 | 510 | 540 |
| Top Tube Length (mm) | 520 | 550 | 580 | 600 | 630 |
| Bottom Bracket Drop (mm) | -75 | -75 | -75 | -75 | -75 |
| Bottom Bracket Height (mm) | 269 | 269 | 269 | 269 | 269 |
| Chainstay Length (mm) | 425 | 425 | 425 | 425 | 425 |
| Seat Tube Angle | 73° | 73° | 73° | 73° | 73° |
| Effective Seat Tube Angle | 74° | 74° | 74° | 74° | 74° |
| Headtube Angle | 70° | 70° | 70° | 70° | 70° |
| Fork Offset (mm) | 45 | 45 | 45 | 45 | 45 |
| Wheelbase (mm) | 1003 | 1035 | 1067 | 1089 | 1121 |
| Headtube Length (mm) | 100 | 125 | 145 | 175 | 200 |
| Reach (mm) | 363 | 386 | 411 | 423 | 446 |
| Stack (mm) | 548 | 572 | 591 | 619 | 642 |
| Stem Length (mm) | 60 | 70 | 70 | 80 | 90 |
| Fork Height (mm) | 420 | 420 | 420 | 420 | 420 |
