Orbea Muga 20 28mph
Product Details
The Orbea Muga 20 28mph is a full-suspension electric bike designed to connect everyday journeys with routes beyond the city. Muga brings mountain-bike thinking to a practical, equipped platform, combining composed handling with the ability to carry what a normal day requires. It suits riders who want a bike to feel reassuring on broken streets, comfortable on longer outings and capable when a paved route gives way to a rough track.
The frame and suspension are designed to work together rather than treating comfort as an accessory. With 120 mm of front travel and 115 mm at the rear, the platform absorbs repeated bumps while helping the rider stay settled and in control. The rear suspension is tuned for a balance of support and comfort, and the shock can be adjusted to the rider. This gives the Muga a different character from a rigid urban bike when the surface becomes uneven or the ride extends beyond familiar roads.
Riding position is equally important. Orbea's adjustable cockpit offers higher or lower and shorter or longer settings, allowing the rider to favor an upright view of traffic or a more active position on rougher ground. A 29-inch front wheel and 27.5-inch rear wheel combine rollover ability with a manageable rear end. The remotely controlled seatpost adds useful flexibility when stopping, mounting a loaded bike or approaching a descent.
The integrated battery keeps the energy system within the frame, and Bosch assistance supports the bike's broad mix of daily and recreational use. Equipment is part of the design from the beginning: the rear carrier, full fenders, lighting and integrated stand make the platform useful before extra accessories are considered. Compatible luggage systems allow the carrier to serve different routines, while the lighting includes a high-beam function for changing conditions. Muga's appeal is this joined-up approach: suspension, fit, assistance and carrying ability all contribute to a bike that can make the practical trip as enjoyable as the optional detour.
Key Features
-
Frame - Orbea Muga 2026, Hydroformed Alloy 6061
-
Motor - Bosch Performance Line Speed CX BDU3883
-
Battery - Bosch PowerTube 750wh
-
Suspension - Fox 34 Float AWL Sport 120 fork and Fox Float Performance Shock
-
Drivetrain - Shimano Cues Di2 U8050 11s SGS Shadow Plus
- Wheelset - Alloy, 26c, 32H
| Specification | Detail |
|---|---|
| Fork | Fox 34 Float AWL Sport 120 Rail 2.0, Kabolt 15x110, Fender and ABS Mts |
| Frame | Orbea Muga 2026, Hydroformed Alloy 6061, OLD 148, Belt drive compatible, Orbea cockpit and equipment ecosystem, w/ Custom Kickstand, Carrier compatible. |
| Shock | Fox Float Performance Trunnion 2-Pos custom tune 165x42.5mm |
| Headset | FSA 1-1/2" Integrated Aluminium Cup |
| Motor | Bosch Performance Line Speed CX BDU3883 |
| Battery | Bosch PowerTube 750 BBP3775 |
| Range Extender | N/A |
| Display | Bosch Purion 400 |
| Charger | Bosch Charger 4A (110V) BPC3410 |
| Remote | Bosch Mini Remote BRC3300 |
| Chainring | Alloy BDU37/38 46t |
| Crank | Prowheel EB03 Alloy |
| Shifters | Shimano EN605-R |
| Cassette | Shimano CS-LG400 11-45t 11-Speed |
| Rear derailleur | Shimano Cues Di2 U8050 11s SGS Shadow Plus |
| Chain | KMC eGlide |
| Handlebar | Orbea Urban, Integrated Light, Rise 30, Width 760 |
| Computer Mount | Smartphone mount SP Connect SPC+ |
| Brakes | Shimano MT420 Hydraulic Disc |
| Brakes Configuration | N/A |
| Wheels | Alloy, 26c, 32H |
| Tires | Schwalbe Johnny Watts Hybrid Radial TLR, 60-622, Radial, Addix Green, Reflective Tape Schwalbe Johnny Watts Hybrid Radial TLR, 60-584, Radial, Addix Green, Reflective Tape |
| Seatpost | OC Mountain Control MC22 |
| Seatpost Remote | OC Dropper Remote for Sram Matchmaker |
| Saddle | Selle Royal Vivo Ergo |
| Rear light | Supernova TL3 Z |
| Pedals | VP-892 Black with reflectors |
| Front carrier | N/A |
| Rear carrier | Orbea RR-02 Alloy, w/MIK HD and MIK Side and Ortlieb QL3.1 system. Max. 30Kg |
| Carrier accessories | N/A |
| Mudguard | Curana Apollo Orbit 70mm |
| Front Position Light | Orbea Integrated |
| Front light | Supernova Starstream Pro, High Beam |
| Quick stand | Orbea Integrated |
| Size | S | M | L | XL |
|---|---|---|---|---|
| Seat Tube (C-T) | 400 | 415 | 430 | 450 |
| Top Tube (EFF) | 602.5 | 636 | 663.3 | 691.7 |
| Head Tube | 130 | 145 | 155 | 170 |
| Chainstay | 466.5 | 466.5 | 466.5 | 466.5 |
| BB Drop | 36 / 55 | 36 / 55 | 36 / 55 | 36 / 55 |
| BB Height | 321 | 321 | 321 | 321 |
| Wheelbase | 1212.5 | 1248.5 | 1277.5 | 1308.5 |
| Head Angle | 66.5 | 66.5 | 66.5 | 66.5 |
| Seat Angle | 76 | 76 | 76 | 76 |
| Rake | - | - | - | - |
| Standover | 779 | 785 | 787 | 793 |
| Reach | 440 | 470 | 495 | 520 |
| Stack | 652 | 665 | 675 | 689 |
| Fork Length | 540 | 540 | 540 | 540 |
