Product Description
The Orbea Occam SL H30 is a versatile bike tailor-made for swift and agile trail adventures. Boasting 140mm of suspension both in the front and rear, it offers generous cushioning to tackle a wide range of terrains, all while avoiding the bulk of larger travel trail bikes. With the added convenience of a Squidlock remote lockout, adjusting the suspension is a breeze—perfect for extended journeys in the mountains. Its lightweight design and dependable suspension enable rapid ascents and confident descents on challenging trails. The Squidlock remote lockout provides an ideal means to fine-tune your suspension on the go, allowing you to fully exploit the terrain's potential.
The H30 is the first of the alloy models- Fox performance suspension ensures you get a tunable setup that won't break the bank. A Shimano Deore drivetrain offers Shimano's legendary reliability, with a light alloy frame, for a responsive ride. While the tubeless ready in house OC alloy wheels and Maxxis tires grip the trails and provide decent braking traction, without the weight of bigger trail tires. Shimano's base level hydraulic brakes keep you at safe speeds though your rides.
REVIEWS
Specifications
*Please note that bike specifications are subject to change without prior notice |
FRAME | Orbea Occam Hydro. Concentric Boost 12x148 rear axle. Pure Trail geometry. Internal cable routing. Asymmetric design. 29" wheels. Linkage compatible with OC multitool |
SHOCK | Fox Float Performance Remote Push-lock Evol custom tune 210x50mm |
FORK | Marzocchi Bomber Z2 140 Remote Push-Lock QR15x110 |
HEADSET | FSA 1-1/2" Integrated Aluminium Cup |
CRANKSET | Forged alloy, 32t |
SHIFTERS | Shimano Deore M6100 |
CASSETTE | Shimano CS-M6100 10-51t 12-Speed |
REAR DERAILLEUR | Shimano Deore M6100 SGS Shadow Plus |
CHAIN | Shimano M6100 |
HANDLEBAR | OC Mountain Control MC30, Rise20, Width 800 |
STEM | OC Mountain Control MC20, 0º |
BRAKES | Shimano MT201 Hydraulic Disc |
WHEELS | Alloy, Tubeless, 29", 29c, 32H |
TYRES | Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR |
TYRES | Maxxis Rekon 2.40" FB 60 TPI Dual Exo TR |
SEATPOST | OC Mountain Control MC21, 31.6mm, Dropper |
SADDLE | Selle Royal 2058 DRN |
GRIPS | OC Lock On |
REMOTE LOCKOUT | OC Squidlock MC20 Remote, Dropper, Suspension 2 Pos |
STORAGE | Accessories Containers |
Geometry
Measurement | S | M | L | XL | S-LT | M-LT | L-LT | XL-LT |
---|---|---|---|---|---|---|---|---|
1 - SEAT TUBE (C-T) | 381 | 419 | 457 | 508 | 381 | 419 | 457 | 508 |
2 - TOP TUBE (EFF) | 565 | 592 | 619 | 649 | 565 | 592 | 619 | 649 |
3 - HEAD TUBE | 95 | 105 | 120 | 140 | 95 | 105 | 120 | 140 |
4 - CHAINSTAY | 440 | 440 | 440 | 440 | 440 | 440 | 440 | 440 |
5 - BB HEIGHT | 336 | 336 | 336 | 336 | 336 | 336 | 336 | 336 |
6 - BB DROP | 35 | 35 | 35 | 35 | 32 | 32 | 32 | 32 |
7 - WHEELBASE | 1165 | 1194 | 1224 | 1259 | 1165 | 1194 | 1224 | 1259 |
8 - HEAD ANGLE | 66º | 66º | 66º | 66º | 65.5º | 65.5º | 65.5º | 65.5º |
9 - SEAT ANGLE | 77º | 77º | 77º | 77º | 76.5º | 76.5º | 76.5º | 76.5º |
10 - STANDOVER | 710 | 736 | 766 | 776 | 710 | 736 | 766 | 776 |
11 - REACH | 425 | 450 | 474 | 500 | 425 | 450 | 474 | 500 |
12 - STACK | 604 | 613 | 627 | 646 | 604 | 613 | 627 | 646 |
13 - FORK LENGTH | 554 | 554 | 554 | 554 | 554 | 561 | 561 | 561 |
RAKE | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 44 |
