Product Description
Cross-country bikes don’t need to rattle your fillings out. Orbea built the Orbea Oiz XC bike by creating a single platform that combines the weight and efficiency of 100mm suspension with the control and traction of 120mm suspension. Add in its race-tuned geometry and low weight, and the new Orbea Oiz M10 bike promises to be faster, smoother, and more comfortable than before
The Oiz M10 uses its OMR carbon frame is seriously lightweight. This is thanks to generations of racing technology at the highest levels. It's modern geometry was developed using feedback from the Team KMC Orbea team. And every model receives not only Fox suspension but Orbea’s own Squidlock lever; this provides a three-position suspension lockout and dropper remote that makes adjustments easy.
Want to customize your Orbea Oiz M10? Orbea offers the MyO Lite customization program to customize components. And if you want to customize even further, the Contender Custom Program can get you exactly the tires, wheels, saddle, and more you might want.
The Orbea Oiz M10 cross-country bike uses:
- Orbea OMR lightweight carbon frame with a 120mm shock
- Fox Factory 34 Stepcast fork with 120mm suspension
- OC Squidlock three-position suspension and dropper remote
- Shimano XT drivetrain
- Oquo MP30Team carbon wheels with DT Swiss 350 hubs
- OC MC20 dropper post
- Maxxis Rekon Race tires (Dissector tires as option)
REVIEWS
Specifications
Model | OIZ M10 |
FRAME | Orbea Oiz Carbon OMR, Fiberlink, Boost, BSA BB, UFO2, I-line shock |
SHOCK | Fox i-line DPS Factory 120mm Remote Push-Unlock Evol Kashima custom tune 190x45mm |
FORK | Fox 34 Float SC Factory 120 FIT4 Remote-Adj Push-Unlock QR15x110 |
CRANKSET | Shimano XT M8100 32t |
HEADSET | Alloy 1-1/2", Black Oxidated Bearing |
HANDLEBAR | OC MP10 Mountain Performance Carbon, Width 760, Sweep 9 |
STEM | OC Mountain Performance MP21, -6º |
SHIFTERS | Shimano XT M8100 I-Spec EV |
BRAKES | Shimano XT M8100 Hydraulic Disc |
CASSETTE | Shimano CS-M8100 10-51t 12-Speed |
REAR DERAILLEUR | Shimano XT M8100 SGS Shadow Plus |
CHAIN | Shimano M7100 |
WHEELS | OQUO Mountain Performance MP30TEAM Carbon |
TYRES | Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR |
SEATPOST | OC Mountain Control MC20, 31.6mm, Dropper |
SADDLE | Fizik Taiga S-alloy rail |
REMOTE | LOCKOUT OC Squidlock MP20 Remote, Dropper, Suspension 3 Pos |
Geometry
SIZE | S | M | L | XL | |
1 | SEAT TUBE (C-T) | 405 | 432 | 460 | 510 |
2 | TOP TUBE (EFF) | 575 | 598 | 623 | 650 |
3 | HEAD TUBE | 90 | 90 | 100 | 115 |
4 | CHAINSTAY | 432 | 432 | 432 | 432 |
5 | BB HEIGHT | 333 | 333 | 333 | 333 |
6 | BB DROP | 42 | 42 | 42 | 42 |
7 | WHEELBASE | 1138 | 1163 | 1189 | 1219 |
8 | HEAD ANGLE | 67º | 67º | 67º | 67º |
9 | SEAT ANGLE | 76.5º | 76.5º | 76.5º | 76.5º |
10 | STANDOVER | 731 | 741 | 741 | 750 |
11 | REACH | 425 | 450 | 472 | 496 |
12 | STACK | 596 | 596 | 606 | 619 |
13 | FORK LENGTH | 531 | 531 | 531 | 531 |
RAKE | 44 | 44 | 44 | 44 |
