Product Description
The 2022 Orbea Orca M20i Team sports a Shimano Ultegra Di2 groupset to provide premium partially wireless shifting. With unprecedented shifting speed, be prepared to cut through the climbs, flats, and descents like they aren’t even there.
Over the past couple of years, Orbea has significantly improved their carbon fiber layups and frame construction. They use their in-house OMR carbon lay-up to carefully reinforce critical frame areas which provide unbelievable stiffness to weight ratios. The forces acting on every part of the frame are taken into consideration and then exactly the right amount of material is utilized to implement strength, rigidity, and weight savings.
The Orca M20i Team effortlessly cheats air resistance. A holistic improvement to essentially every aspect of the Orca M20i Team yields an eager responsiveness from the bike. In the name of optimization, Orbea specifically designed down tube and seat tube for 25-30mm tires. Tire selection is a very personal decision and Orbea puts the power in your hands.
Comfort is often an aspect that falls through the cracks in creating sleek road bikes. An uncomfortable cyclist is a slow cyclist; if you’re constantly shifting about in search of a pleasant position, you’re creating lots of drag. You’re also mentally distracted from the road in front of you. One of our favorite aspects about the 2022 Orbea Orca M20i Team is the ease of customization. Orbea designed the Orca M20i Team without a fully integrated cockpit to provide handlebar adjustability because they know that everyone has different reach numbers, flexibility, and riding styles.
Rotate your bars, change stem length, rotate your seat angle, and make your competition regret their back-killing one-position integrated bar/stems. Fast can, and must, be comfortable; always remember, optimized dynamics are faster than trivial weight savings.
REVIEWS
Specifications
Orca M20i Team | |
Frame | Orbea Orca carbon OMR Disc, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing, EC/DC compatible |
Fork | Orbea Orca OMR ICR fork 2021, full carbon, 1-1/8" - 1.5" tappered head tube compatible, Thru axle 12x100m, thread M12x2P1, Speed release compatible droput. |
Crankset | Shimano Ultegra R8100 34x50t |
Headset | Acros Alloy 1-1/2" Internal Cable Routing |
Handlebar | OC RP20 Road Performance SL, Reach 80, Drop 125, w/Di2 hole |
Stem | OC RP10 Road Performance ICR, -8º, IFC02 Computer mount interface |
Shifters | Shimano ST-8170 |
Brakes | Shimano R8170 Hydraulic Disc |
Cassette | Shimano Ultegra R8100 11-30t 12-Speed |
Rear Derailleur | Shimano Ultegra Di2 R8150 |
Front Derailleur | Shimano Ultegra Di2 R8150 |
Chain | Shimano M8100 |
Wheels | FULCRUM Racing 600 DB |
Tires | Vittoria Rubino IV G2.0 Foldable 700x28c |
Seatpost | OC XP10 Performance Carbon SB20, 27,2mm, w/Micro tilt adjustment |
Saddle | Prologo Scratch-M5 Pas T2.0 size 140mm |
Handlebar Plugs | Orbea Anti-Slippery/Shock Proof |
Front Wheel Axle | Orbea Thru Axle 12x100mm M12x2 P1 Hollow |
Rear Wheel Axle | Orbea Thru Axle 12x142mm M12x2 P1 Hollow |
Geometry
Size | 47 | 49 | 51 | 53 | 55 | 57 | 60 |
1 - Seat Tube (C-T) | 440 | 460 | 480 | 500 | 520 | 540 | 570 |
2 - Top Tube (EFF) | 510 | 523 | 535 | 548 | 560 | 576 | 590 |
3 - Head Tube | 105 | 113 | 130 | 148 | 168 | 186 | 213 |
4 - Chainstay | 408 | 408 | 408 | 408 | 408 | 408 | 408 |
5 - BB Height | 267 | 267 | 267 | 269 | 269 | 269 | 269 |
6 - BB Drop | 72 | 72 | 72 | 70 | 70 | 70 | 70 |
7 - Wheelbase | 972 | 976 | 980 | 981 | 991 | 1002 | 1016 |
8 - Head Angle | 71º | 71.5º | 72.2º | 72.8º | 73º | 73.2º | 73.2º |
9 - Seat Angle | 74.5º | 74º | 73.7º | 73.5º | 73.5º | 73.2º | 73.2º |
10 - Standover | 735 | 747 | 766 | 787 | 807 | 825 | 851 |
11 - Reach | 367 | 372 | 377 | 382 | 388 | 395 | 401 |
12 - Stack | 513 | 522 | 540 | 559 | 579 | 597 | 623 |
13 - Fork Length | 370 | 370 | 370 | 370 | 370 | 370 | 370 |
Rake | 48 | 48 | 48 | 43 | 43 | 43 | 43 |
