Product Description
Terra, Mother Earth in ancient Rome, is a wide, wonderful place full of life and beauty. Ride the 2023 Orbea Terra H40 all-road endurance bike and experience all you can see.
Ride mountains, valleys, plains and river trails - or maybe just the urban bike path to and from work - on the 2023 Orbea Terra H40. An all-road endurance bicycle that’s as at home on a country dirt road as it is the city highway.
With progressive, comfortable ergonomically designed geometry, the Orbea Terra H40 is truly a vehicle for virtually all roads and all rides.
The Orbea Terra H40 uses a specially designed hydroformed alloy frame with a carbon fork to create an ultra comfortable bicycle. There’s no simple widening of the fork and seat stays and slapping a “gravel bike” label on Orbea’s Terra line of bikes. The more upright and relaxed riding position may not be as aggressive and ‘racey’ as some bikes, but the objective with the Orbea Terra H40 is more about exploring the world than it is about crushing it.
Of course, if you’re the crushing kind, go ahead and crush.
Racing cyclocross or monster gravel events is second nature for the Orbea Terra H40. First nature is, well, it’s nature. Find a forest road and pedal. Just pedal.
Maybe that road is the shortest route to the summit over yonder. Maybe it’s not. Either way, just pedal.
Ride it as a commuter, but remember to take the long way home every now and then.
REVIEWS
Specifications
FRAME | Orbea Terra Hydro disc, hydroformed triple butted aluminium, tapered 1-1/8" - 1,5", BB 68mm – BSC English, Thru Axle 12mm x 142mm rear, thread M12x P1.5, DT internal cable routing, 27,2mm seat tube, MMS system |
FORK | Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system |
CRANKSET | Shimano GRX RX600-10 30x46t |
HEADSET | FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings |
HANDLEBAR | OC1 All Road, reach 80mm, drop 125mm, flare 12º |
STEM | OC1 31.8mm interface -6º |
SHIFTERS | Shimano ST-RX400 |
BRAKES | Shimano RX400 Hydraulic Disc |
CASSETTE | Shimano Tiagra HG-500 11-34t 10-Speed |
REAR DERAILLEUR | Shimano RD-RX400 |
FRONT DERAILLEUR | Shimano GRX RX400 |
CHAIN | KMC X10 |
WHEELS | Orbea wheel: Ready GR with 12mm E-Thru hubset Shimano RS470 28H |
TYRES | Vittoria Terreno Dry Gravel G2.0 TNT 700x38c |
SEATPOST | OC2 Carbon 27.2 Offset 20 |
SADDLE | Selle Royal Seta RS |
HANDLEBAR PLUGS | Orbea Eva |
FRONT WHEEL AXLE | Orbea Thru Axle 12x100mm M12xP1.5 Hollow|
REAR WHEEL AXLE | Orbea Thru Axle 12x142mm M12xP1.5 Hollow |
Geometry
1 - SEAT TUBE (C-T) | 455 | 485 | 515 | 545 | 575 | 605 |
2 - TOP TUBE (EFF)512 | 529 | 542 | 560 | 575 | 588 | |
3 - HEAD TUBE | 100 | 120 | 139 | 162 | 187 | 205 |
4 - CHAINSTAY | 430 | |||||
5 - BB HEIGHT | 285 | |||||
6 - BB DROP | 70 | 70 | 68 | 66 | 66 | 66 |
7 - WHEELBASE | 1005 | 1015 | 1020 | 1034 | 1046 | 1052 |
8 - HEAD ANGLE | 70,5 | 71 | 72 | 72 | 72,3 | 73 |
9 - SEAT ANGLE | 74,5 | 74 | 74 | 73,5 | 73,5 | 73,5 |
10 - STANDOVER | 763 | 787 | 813 | 839 | 866 | 890 |
11 - REACH | 366 | 373 | 380 | 387 | 394 | 401 |
12 - STACK | 525 | 545 | 565 | 585 | 610 | 630 |
13 - FORK LENGTH | 400 | |||||
RAKE | 51mm | |||||
WHEEL SIZE | 702 |
