Otso Voytek GX AXS Build
Product Description
The Otso Voytek GX AXS mountain bike is light and agile, and cuts easily through sharp single track turns. The agressive XC geometry paired with a narrow pedal stance, achieves high performance when traveling over snow and other challenging terrain. When the season transitions and the snow turns to dirt, swap out the 26" fat wheelset for a 29" MTB wheelset to ride this bike all year round.
- The Voytek has the narrowest Q-factor of any fat bike in the world at 183mm. With a narrow Q-factor, your weight is closer to the centerline of the bike.
- The SRAM GX AXS upgrade kit allows for wireless drivetrain simplicity.
- Fitted with Shamino M8100 brakes
The Voytek is a an extremely versatile fat bike with a narrow q-factor, adjustable dropouts, and quality components. This build will take you to places that most bikes can't, all while giving you pleasant ride and feel for the trail.
REVIEWS
Specs
| Wheel Size: | 26" or 27.5" |
| Fat Fork: | Voytek Rigid Carbon, 15x150mm |
| Wheelset: | SunRingle MulFut 80mm with SunRingle Hubs |
| Tires: | Terrene Cake Eater 26x4.0 Light Folding or 45Nrth Dillinger 4 27.5x3.8 |
| Drivetrain: | SRAM GX AXS 12spd |
| Crankset: | Race Face Aeffect with WTC CAMO CAMO Chainring Bolt Color: Black |
| Chainring: | 32T Round Aluminum |
| Brakes: | Shimano M8100 |
| Headset: | Wolf Tooth Performance Headset - black Ano |
| Accent Color: | Black |
| Stem: | Race Face Ride |
| Handlebar: | Race Face Ride 31.8 x 740mm 1" Rise |
| Grips: | Wolf Tooth Fat Paw - Black |
| Seatpost: | Race Face Ride, 30.9x375mm |
| Saddle: | WTB Volt 142mm width, 316g |
| Tubes or Tubeless: | Tubes with rim strips |
Geometry
| Recommended rider height | 4'9"-5'5" | 5'4-5'9" | 5'8"-6'1" | 6'0"-6'7" |
| Recommended rider inseam | 29"-32" | 31"-33" | 32"-35" | 34"-37" |
| Effective top tube | 585mm | 610mm | 630mm | 645mm |
| Nominal head tube angle (rigid and 100mm suspension fork) | 69° | 69° | 69° | 69° |
| Nominal head tube angle (120mm suspension fork) | 68.5° | 68.5° | 68.5° | 68.5° |
| Tuning Chip induced head/seat tube angle change | ±0.2° | ±0.2° | ±0.2° | ±0.2° |
| Head tube length | 90mm | 115mm | 130mm | 150mm |
| Nominal seat tube angle | 73° | 73° | 73° | 73° |
| Seat tube length | 381mm | 432mm | 483mm | 533mm |
| Bottom bracket drop | 58-62mm | 58-62mm | 58-62mm | 58-62mm |
| Chainstay length | 430-450mm | 430-450mm | 430-450mm | 430-450mm |
| Wheelbase | 1092-1112mm | 1118-1138mm | 1139-1159mm | 1156-1176mm |
| Trail | 85.5mm | 85.5mm | 85.5mm | 85.5mm |
| Fork offset | 51mm | 51mm | 51mm | 51mm |
| Rigid fork axle to crown length | 485mm | 485mm | 485mm | 485mm |
| Stack | 581mm | 602mm | 616mm | 634mm |
| Reach | 407mm | 426mm | 442mm | 451mm |
| Standover | 697mm | 739mm | 780mm | 815mm |
