Pinarello Dogma GR SRAM Red XPLR 1x13 PM

$14,500.00
$14,500.00 $14,500.00

Please note: Images are shown for color reference only. For accurate details and components, please refer to the specifications.

Color
Size
Your satisfaction is our top priority.

Contender Signature Service
A complimentary $300 value covering professional assembly, tuning, inspection, and careful re-packaging by our technicians.

Learn more about Contender Signature Service

Request Info

Pinarello Dogma GR SRAM Red XPLR 1x13 PM

Online Enquiries

Phone: 801.364.0344

Locations

Product Details

The Pinarello Dogma GR SRAM Red XPLR represents the end of excuses, combining the pure speed of the legendary Dogma F with the off-road dominance of Crossista and Dogma XC. Designed to be the fastest gravel race bike imaginable, it is engineered with Pinarello’s World Tour–proven expertise and equipped with SRAM’s flagship wireless electronic drivetrain for uncompromising race performance.

Built around an advanced Torayca M40X carbon frame with TiCR™ cable routing and an Italian bottom bracket, the Dogma GR features race-optimized gravel geometry designed to extract maximum effort from the rider. Carefully tuned seattube and headtube angles create an aerodynamic, power-efficient riding position while maintaining front-end stability and confidence—essential traits for high-speed gravel racing. The evolved aerodynamic headtube “nose” shape minimizes frontal volume and width, improving airflow efficiency and reducing drag.

At the front end, the innovative E-TiCR elliptical steering tube integrates a newly developed headset with differentiated bearings—wider at the bottom and narrower at the top—allowing a slimmer headtube profile without sacrificing stiffness or control. The adaptive seatpost is engineered to balance aerodynamics, stiffness, and vibration absorption, helping maintain correct saddle position and consistent power delivery across rough and demanding terrain.

Performance is elevated by the SRAM Red XPLR 1x13 wireless electronic drivetrain with an integrated power meter, delivering flagship-level shifting precision, reliability, and advanced training data in a clean, cable-free setup. Princeton Grit 4540 carbon wheels provide aerodynamic efficiency, stability, and confidence across all gravel conditions. With generous tire clearance of up to 45mm front and 42mm rear (as measured), the Dogma GR allows riders to fine-tune their setup for varying race surfaces.

Completed with the Talon Ultra Fast GR handlebar—featuring a 7° flare, 7° inward bend, and compatibility with optional Gravel TT Bars—and a hidden front thru-axle for improved aerodynamics and a clean fork profile, the Pinarello Dogma GR SRAM Red XPLR is built for elite gravel racers who demand World Tour–level speed, premium components, and wireless precision.

Key Features

  • Frame – Pinarello Dogma GR Torayca M40X Carbon
  • Drivetrain – SRAM Red XPLR 1x13 with integrated power meter
  • Wheelset – Princeton Grit 4540 carbon wheels
*Please note that specifications are subject to change without prior notice
Specification Detail
Frame Torayca M40X, TiCR™ Cable Routing, Italian BB
Fork NEW eTICR Onda Fork with ForkFlap™, 1.5" upper and lower steerer
Crankset & Chainrings SRAM RED XPLR AXS 1x13
Rear Derailleur SRAM RED XPLR AXS 1x13
Cassette SRAM RED XPLR AXS 1x13
Chain SRAM Red
Bottom Bracket SRAM BB DUB ITALIAN 70mm ROAD WIDE
Front Brake Sram Red, 2-piston caliper, 160mm rotor
Rear Brake Sram Red, 2-piston caliper, 160mm rotor
Handlebar Talon Ultra Fast GR (Integrated)
Bar Tape MOST bar tape
Saddle Lynx 2.0 XC
Seatpost Pinarello Aero seatpost with 3D printed titanium top seat clamp and bolts
Wheelset Princeton Grit 4540 DB
Tyres Maxxis Reaver 40mm
Axles NEW MOST Ultralight Custom Axle, 12x100 front / 12x142 rear, tool-free removal
Accessories Bottlecage Trap PACF ø74mm, Fly Bottle Pinarello 550ml Black
Measurement 43 46.5 50 51.5 53 54.5 56 57.5 59.5
Seat Tube Center–End (mm) 415 425 450 465 485 500 515 525 540
Seat Tube Center–Center (mm) 430 465 500 515 530 545 560 575 595
Top Tube Center–Center (mm) 515 520 530 540 550 562 575 585 605
Setback (mm) 115.6 125 137.8 144.5 148.8 155.7 163.7 168.1 179.9
Seat Tube Angle (°) 74.4 74.4 74.0 73.7 73.7 73.4 73.0 73.0 72.4
Head Tube Angle (°) 70.0 70.5 70.5 71.0 71.0 71.0 71.5 72.0 72.5
Chainstay (mm) 425 425 425 425 425 425 427 427 427
Head Tube (mm) 115 121 130 137 150 165 180 200 228
BB Drop (mm) 72 72 72 72 72 72 72 72 72
Fork Rake (mm) 50 50 50 50 50 50 50 50 50
Fork Height (mm) 390 390 390 390 390 390 390 390 390
Wheelbase (mm) 996 1000 1008.8 1012.6 1023.4 1033.1 1037.9 1043.6 1052.5
Reach (mm) 355 361.1 366.9 372.6 379.1 384 388.6 392.7 398
Stack (mm) 536 543.6 552.1 560.6 572.9 587.1 603.3 624.3 653
