Santa Cruz Nomad 7 CC XT Di2 Coil
Product Details
The Santa Cruz Nomad 7 CC XT Di2 is built for riders who live for big hits, steep lines, and all-out descents, then endure the climbs just long enough to do it all again. Completely redesigned around Santa Cruz’s refined VPP suspension platform, it delivers improved climbing efficiency, reduced braking feedback, and exceptional traction across the roughest terrain. The result is a more composed, confident, and capable enduro machine that thrives when things get rowdy.
At its core, the Carbon CC MX frame delivers 170mm of travel, combining strength, compliance, and reduced weight for aggressive riding. Updated VPP kinematics refine anti-squat and anti-rise characteristics for smoother suspension behavior under power and braking, improving traction and control in demanding conditions. A slacker head angle and steeper seat angle enhance descending stability while maintaining efficient climbing position.
Premium FOX suspension and a high-end Shimano drivetrain make the Nomad a true performance weapon. The FOX 38 Float Factory Grip X2 fork and FOX DHX2 Factory shock provide elite-level control and big-hit confidence, while the Shimano XT M8250 Di2 12-speed wireless drivetrain delivers precise, rapid shifting under load. Reserve 30|HD alloy wheels with DT Swiss 350 hubs add durability and strength for aggressive enduro terrain.
Key Features
- Frame - Carbon CC MX, 170mm Travel VPP Suspension
- Suspension - FOX 38 Float Factory Grip X2 Fork & FOX DHX2 Factory Shock
- Drivetrain - Shimano XT M8250 Di2 12-Speed Wireless Drivetrain
- Wheelset - Reserve 30|HD Alloy Rims with DT Swiss 350 DEG Hubs
| Specification | Detail |
|---|---|
| Frame | Carbon CC MX 170mm Travel VPPTM |
| Rear Shock | Fox DHX2 Factory - S: 400lb, M: 450lb, L: 500lb, XL-XXL: 550lb |
| Fork | Fox 38 Float Factory, Grip X2, 170mm |
| Rear Derailleur | Shimano XT M8250 Di2, SGS, 12spd |
| Shifter | Shimano Deore XT M8250 Shift Switch |
| Cassette | Shimano XT M8200, 10-51t |
| Chain | Shimano XT M8100, 12spd |
| Chain Guide | OneUp Chainguide |
| Bottom Bracket | Shimano MT801 Threaded |
| Headset | Cane Creek 50 IS Integrated Headset |
| Rear Tire | Maxxis High Roller, 29"x2.4", 3C Maxx-Grip, EXO+ |
| Front Tire | Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, Double Down |
| Front Hub | DT Swiss 350, 15x110, 6-Bolt, 28h |
| Front Rim | Reserve 30|SL AL 6069 |
| Rear Hub | DT Swiss 350 DEG DF, 12x148, MicroSpline, 6-Bolt, 32h |
| Rear Rim | Reserve 30|HD AL 6069 |
| Front Rotor | SRAM HS2 200mm |
| Rear Rotor | SRAM HS2 200mm |
| Brakes | SRAM Maven Silver |
| Crankset | Shimano XT M8200, 32t |
| Handlebar | OneUp Aluminum Bar, 35mm |
| Stem | OneUp Enduro Stem (All Sizes: 42mm) |
| Saddle | WTB Silverado Medium Fusion, CroMo SL |
| Seatpost | OneUp Dropper Post, 31.6 - S: 150mm, M: 180mm, L-XL: 210mm, XXL: 240mm |
| Grips | Santa Cruz Bicycles House Grips |
| Measurement | S | M | L | XL | XXL |
|---|---|---|---|---|---|
| Reach (Hi/Lo) (mm) | 435 / 433 | 455 / 453 | 475 / 473 | 495 / 493 | 520 / 518 |
| Stack (Hi/Lo) (mm) | 624 / 626 | 633 / 635 | 643 / 645 | 660 / 662 | 669 / 671 |
| Head Tube Angle (Hi/Lo) (°) | 63.6° / 63.3° | 63.6° / 63.3° | 63.6° / 63.3° | 63.6° / 63.3° | 63.6° / 63.3° |
| Head Tube Length (mm) | 100 | 110 | 120 | 140 | 150 |
| Rear Center (Hi/Lo) (mm) | 438 / 439 | 441 / 442 | 444 / 445 | 447 / 448 | 451 / 452 |
| Front Center (Hi/Lo) (mm) | 781 / 780 | 805 / 805 | 830 / 830 | 858 / 858 | 888 / 888 |
| Bottom Bracket Height (Hi/Lo) (mm) | 346 / 342.5 | 346 / 342.5 | 346 / 342.5 | 346 / 342.5 | 346 / 342.5 |
| BB Drop Front (Hi/Lo) (mm) | 26.5 / 30 | 26.5 / 30 | 26.5 / 30 | 26.5 / 30 | 26.5 / 30 |
| BB Drop Rear (Hi/Lo) (mm) | 8 / 11.5 | 8 / 11.5 | 8 / 11.5 | 8 / 11.5 | 8 / 11.5 |
| Wheelbase (Hi/Lo) (mm) | 1219 / 1219 | 1246 / 1247 | 1276 / 1274 | 1305 / 1306 | 1339 / 1339 |
| Top Tube Length (Hi/Lo) (mm) | 569 / 569 | 587 / 586 | 604 / 605 | 627 / 628 | 651 / 652 |
| Seat Tube Length (mm) | 380 | 400 | 420 | 450 | 500 |
| Seat Tube Angle (Hi/Lo) (°) | 78° / 77.7° | 78.2° / 78.1° | 78.6° / 78.4° | 78.7° / 78.5° | 78.9° / 78.7° |
| Seat Tube Angle at Saddle Height (Hi/Lo) | 77.4 / 77.1 at 680 | 77.4 / 77.1 at 730 | 77.4 / 77.1 at 780 | 77.4 / 77.1 at 830 | 77.4 / 77.1 at 870 |
| Standover Height (Hi/Lo) (mm) | 711 / 707 | 719 / 715 | 722 / 718 | 726 / 722 | 732 / 728 |
