Product Description
You might not like the idea of a suspension remote on your handlebars, but the new Genius ST trail bike will change that. With its Fox Float X and onboard Ramp Adjust control, this bike is designed to make sure you get down the mountain in a hurry. And if you’re looking for the top-spec version, the SCOTT Genius ST 900 Tuned is the bike in its top level. Call it the most ‘Tuned’ model, if you'd like.
The base of the SCOTT Genius is its Integrated Suspension Technology or a fancy name for hiding its rear suspension inside of the frame. You read that right: the shock is INSIDE the frame. To make it work, SCOTT has a built-in sag indicator for every Genius, found on the non-drive side of the bike’s rocker link. SCOTT says it gives the frame a lower center of gravity. Importantly, however, mounting the shock lower means the frame is stiffer around the bottom bracket without adding any extra weight.
Want to access the shock? That is found through a downtube door available at a push of a button, also doubling as durable bottom bracket protection.
The Genius ST utilizes a Fox Float X shock. Rather than using SCOTT’s typical TwinLoc suspension remote controlling both fork and shock, the Genius ST features a lever that adjusts just how progressive or linear the shock is. Keep the shock in the ‘Descend’ mode if you’re looking for a plush rear end for keeping your tire glued to the ground. Put the shock in the middle ‘Ramp Control’ setting if you’re riding flow trails with lots of compressions, berms, and drops. Call it similar to adding or removing a volume spacer with the flip of a switch.
Want to customize your SCOTT Genius ST? Let’s talk and make your bike exactly what you want it to be, from changing wheels to saddle, tires, and more.
The SCOTT Genius ST 900 Tuned receives these build specifications:
- Genius Carbon HMX Frame
- FOX 36 Float Factory Grip 2 160mm
- FOX FLOAT X Nude, TracLoc, 150mm
- SRAM X01 Eagle AXS 12 Speed
- Shimano XTR 4 Piston Disc Brakes
- Maxxis Foldable Tires
REVIEWS
Specifications
*Please note that bike specifications are subject to change without prior notice | |
Model | Genius ST 900 Tuned |
FRAME | Genius Carbon HMX, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline |
FORK | FOX 36 Float Factory Grip 2 Air / Kashima, HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle, 44mm offset / tapered steerer, 160mm travel |
REAR SHOCK | FOX FLOAT X NUDE Factory EVOL Piggy Back Trunnion, Kashima / SCOTT custom w. travel / geo adj., 3 modes: Climb-Traction Control-Descend, Custom large Air volume / Comp & Reb. Adj. Travel 150-100-Climb / T185X55mm |
REMOTE SYSTEM | TracLoc Technology, Rear Suspension & Dropper Remote, 3 Rear Suspension modes |
REAR DERAILLEUR | SRAM X01 Eagle AXS / 12 Speed, Wireless Electronic Shift System |
SHIFTERS | SRAM GX Eagle AXS Rocker Controller |
CRANKSET | SRAM X01 DUB Eagle Carbon crankarm, 55mm CL / 32T, BB-SETSRAM DUB PF 92 MTB Wide / shell 41x92mm |
CHAIN | SRAM CN X01 Eagle |
CASSETTE | SRAM X01 XG1295 / 10-52 T |
BRAKES | Shimano XTR M9120 4 Piston Disc |
ROTOR | Shimano SM-RT76 / 6 Bolt / 203/F and 180/R |
HANDLEBAR | Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips |
SEATPOST | Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm, L size 170mm / XL size 200mm |
SEAT | Syncros Tofino 1.5 Regular, Titanium rails |
HEADSET | Syncros - Acros Angle adjust & Cable Routing HS System, Stainless / +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
WHEELSET | Syncros Revelstoke 1.0-30 CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready Carbon rim 28H, DT Swiss Ratchet Hubs / XD Driver, SRAM TyreWiz / Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
FRONT TIRE | Maxxis Minion DHF / 2.6" / 120TPI Foldable, Tubeless Ready / EXO 3C maxxTerra |
REAR TIRE | Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxxTerra |
EXTRAS | SRAM AXS Powerpack, SRAM TyreWiz, Syncros Fork Fender |
ACCESSORIES | Syncros Eco Sealant, Transport Axle |
APPROX WEIGHTS IN KG | 13.3 (Tubeless setup) |
APPROX WEIGHTS IN LBS | 29.32 (Tubeless setup) |
MAX. SYSTEM WEIGHT | 128kg, The overall weight includes the bike, the rider, the equipment, and possible additional luggage. |
Geometry
S | M | L | XL | ||
A | HEAD TUBE ANGLE (-0.6° HEADSET SETTING) | 63.9 ° | 63.9 ° | 63.9 ° | 63.9 ° |
B | HEAD TUBE LENGTH | 90.0 MM | 100.0 MM | 120.0 MM | 135.0 MM |
C | TOP TUBE HORIZONTAL | 570.1 MM | 602.2 MM | 631.3 MM | 659.3 MM |
D | STANDOVER HEIGHT | 728.5 MM | 738.5 MM | 753.5 MM | 768.5 MM |
E | BB OFFSET | -33.0 MM | -33.0 MM | -33.0 MM | -33.0 MM |
F | BB HEIGHT | 342.5 MM | 342.5 MM | 342.5 MM | 342.5 MM |
G | WHEEL BASE | 1,195.0 MM | 1,229.0 MM | 1,263.0 MM | 1,294.0 MM |
I | BB CENTER TO TOP OF SEATTUBE | 380.0 MM | 410.0 MM | 440.0 MM | 470.0 MM |
J | SEAT ANGLE | 76.8 ° | 77.1 ° | 77.2 ° | 77.4 ° |
K | CHAINSTAY | 440.0 MM | 440.0 MM | 440.0 MM | 440.0 MM |
L | REACH | 430.0 MM | 460.0 MM | 485.0 MM | 510.0 MM |
M | STACK | 617.0 MM | 626.1 MM | 644.2 MM | 657.8 MM |
N | STEM LENGTH | 40.0 MM | 40.0 MM | 40.0 MM | 40.0 MM |
0 | TRAIL | 125.8 MM | 125.8 MM | 125.8 MM | 125.8 MM |
P | FORK LENGTH | 571.0 MM | 571.0 MM | 571.0 MM | 571.0 MM |
Q | MAXIMUM SEATPOST INSERTION | 173.0 MM | 204.0 MM | 234.0 MM | 265.0 MM |
R | CRANK LENGTH | 170.0 MM | 170.0 MM | 170.0 MM | 170.0 MM |
