Specialized Turbo Vado Evo 3 5.0
Product Details
The Specialized Vado 3 EVO is a versatile electric bike built to deliver confident power, comfort, and capability for everyday rides and extended adventures.
Designed for riders who want to go farther and explore beyond smooth pavement, the Vado 3 EVO combines refined electric assistance with practical versatility for commuting, fitness rides, and fully loaded weekend escapes. Its cleanly integrated design pairs everyday usability with advanced technology, creating an e-bike that feels natural, stable, and intuitive across a wide range of riding conditions.
At the heart of the system is Specialized’s Turbo 3.1 drive unit, derived from the performance-focused Levo platform and tuned specifically for calm, natural amplification during everyday riding. The result is smooth and predictable support that enhances the riding experience without feeling overwhelming, helping riders climb easier, accelerate confidently, and maintain momentum with less effort.
Comfort and control are central to the Vado 3 EVO experience. Suspension, geometry, and handling have been developed by Specialized’s Ride Dynamics team to improve confidence on rough pavement, bike paths, gravel connectors, and uneven urban terrain. The stable ride quality encourages longer rides while reducing fatigue during daily commutes or all-day outings.
A large-capacity internal battery supports extended range for bigger plans and longer adventures, while optional Range Extender compatibility provides even more flexibility for riders pushing deeper into exploration. Integrated security features, Specialized app connectivity, and a seamless technology ecosystem help simplify ownership and enhance the overall riding experience.
Built for real-world practicality, the Vado 3 EVO is cargo-ready, child-seat compatible, and adaptable for everything from weekday errands to spontaneous weekend escapes. It is an e-bike designed not just for transportation, but for expanding how and where riders choose to move through everyday life.
Key Features
-
Frame - Vado 3 frame
-
Motor - Specialized 3.1 Motor, 105Nm torque, 810W power
-
Battery - Specialized 840Wh battery
-
Suspension - SR Suntour suspension fork
-
Drivetrain - Shimano CUES 11-speed
- Wheelset - Rims 27.5" front and rear
| Specification | Detail |
|---|---|
| Battery | 840Wh battery |
| Motor | Specialized 3.1 Motor, 105Nm torque, 810W power |
| Charger | Specialized 4A Charger |
| UI / Remote | Turbo Ergonomic Remote |
| Frame | Vado 3 Frame, comfort optimized geometry, side entry battery |
| Seat Binder | Alloy, 38.6mm |
| Fork | SR Suntour suspension fork, 120mm travel (100mm size S), 34mm stanchions, 15mm thru-axle, 27.5" wheel |
| Front Brake | TEKTRO HD-T5040, 4-piston caliper, extra-thick 2.3mm rotor, 5mm brake pads |
| Rear Brake | TEKTRO HD-T5040, 4-piston caliper, extra-thick 2.3mm rotor, 5mm brake pads |
| Crankset | 170mm, CL 55mm, BCD 110mm, 48T, with chain guard |
| Chainrings | 40T with Chain Retention Technology |
| Chaincase | Vado 3 Custom Chaincase |
| Chain | KMC eGlide for 11-Speed CUES |
| Shift Levers | Shimano 11-Speed RAPIDFIRE PLUS, Short Reach Spec |
| Rear Derailleur | Shimano CUES 11-Speed with Shadow Plus |
| Cassette | Shimano CUES CS-LG400-11, 11-Speed, 11-50T |
| Rims | 27.5", 30mm internal width, 32H |
| Spokes | DT Swiss Elemental |
| Inner Tubes | Reinforced anti-flat 27.5 x 2.5/2.7, Schrader valve, 60mm |
| Front Hub | Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32H |
| Rear Hub | Specialized alloy disc hub, sealed cartridge bearings, 6-bolt, 12x148mm thru-axle, 32H, HG steel freehub |
| Front Tire | Specialized Hemisphere Flat Resistant AllTerrain Reflect 27.5 x 2.6 |
| Rear Tire | Specialized Hemisphere Flat Resistant AllTerrain Reflect 27.5 x 2.6 |
| Saddle | Body Geometry Rivo 2 Gel, 168mm |
| Stem | Cockpit with Integrated Colored Touch Screen Display |
| Handlebars | Integrated Cockpit |
| Seatpost | Lower Suspension Post, 100-125mm travel, 40mm suspension, 34.9mm, 0mm offset |
| Grips | Specialized Body Geometry |
| Bell | Bell |
| Fenders | Vado 3 Custom Alloy Profile Fenders |
| Kickstand | Vado 3 Custom Kickstand with Adjustable Shoe |
| Rack | Vado 3 Custom Seatstay Mounted MIK HD Rack, 27kg Max Load |
| Bike Lock | Mechanical Battery Lock with Matching Wheel Lock Key |
| SWAT | MIK HD 27.5kg rear rack with integrated elastics, compatible with optional 10kg MIK front rack |
| Taillight | Spanninga Rack Integrated Rear Light with Brake Light |
| Headlight | Supernova Custom Cockpit Integrated Hi/Low-Beam, 805lm / 450lm |
| Pedals | Turbo Pedals, anti-slip |
| Weight | 29.9kg (65 lb, 14.7 oz), Size MD |
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Crank Length (mm) | 170 | 170 | 170 | 170 |
| Handlebar Width (mm) | 730 | 730 | 730 | 730 |
| Saddle Width (mm) | 168 | 168 | 168 | 168 |
| Seatpost Length (mm) | 400 | 400 | 450 | 450 |
| Stack (mm) | 636 | 645 | 659 | 682 |
| Reach (mm) | 430 | 450 | 470 | 485 |
| Head Tube Length (mm) | 135 | 120 | 135 | 160 |
| Head Tube Angle (°) | 67° | 68° | 68° | 68° |
| Bottom Bracket Height (mm) | 293.5 | 293.5 | 293.5 | 293.5 |
| Bottom Bracket Drop (mm) | 66.5 | 66.5 | 66.5 | 66.5 |
| Trail (mm) | 105 | 98 | 98 | 98 |
| Fork Length (Full) (mm) | 501 | 521 | 521 | 521 |
| Fork Rake / Offset (mm) | 44 | 44 | 44 | 44 |
| Front Center (mm) | 772 | 734 | 460 | 784 |
| Chainstay Length (mm) | 470 | 470 | 470 | 470 |
| Wheelbase (mm) | 1185 | 1197 | 1222 | 1247 |
| Top Tube Length (Horizontal) (mm) | 612 | 635 | 659 | 681 |
| Bike Standover Height (mm) | 768 | 806 | 821 | 854 |
| Seat Tube Length (mm) | 385 | 440 | 460 | 500 |
| Seat Tube Angle (°) | 74° | 74° | 74° | 74° |
